Siemens Miniature Circuit Breaker, 1-Pole, 1A, Type D, 240V AC, 48V DC, 10 kA Breaking Capacity, Toggle 278569 FAZ-D1/1
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Siemens |
| Model | 278569 FAZ-D1/1 |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 1A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Equipped with thermal magnetic tripping mechanism ensuring fast response to overcurrent.
- Instantaneous break time for quick circuit interruption.
- Toggle switch reset actuator allows easy manual resetting.
- Screw terminals for secure and stable wiring connections.
- Compact size with dimensions 80mm depth and 66mm width suitable for DIN rail mounting.
- Breaking capacity of 10kA for handling significant fault currents.
- IP20 rating making it touch-safe during operation.
- Operational temperature range from -25°C to +75°C for use in harsh environments.
Product Description
Eaton 278569 FAZ-D1/1 Miniature Circuit Breaker is a specialized 1-pole electrical protection device providing a current rating of 1A with tripping characteristics type D. It is designed for use with both 240V AC and 48V DC electrical systems and offers a breaking capacity of 10 kA to safely interrupt fault currents.
The breaker is mounted on DIN rails and features screw-type terminals that afford reliable electrical connections. Its toggle switch reset actuator allows quick and convenient manual resetting after tripping events. The device operates with a thermal magnetic mechanism that detects abnormal current surges and interrupts them instantaneously.
With an IP20 rating, this miniature circuit breaker safeguards users against accidental electrical contact, making it suitable for residential, commercial, and light industrial applications. Its compact dimensions of 80 mm depth and 66 mm width allow it to fit into constrained panel spaces efficiently.
The FAZ xEffect series breaker operates effectively across a wide temperature range from -25°C to +75°C, thus providing resilient performance in various environmental conditions. The mechanical life of 10,000 operations guarantees reliability over extended service periods.
Typical applications include electrical distribution panels in industrial settings, commercial buildings, automation systems, and residential circuit protection. It is a critical safety component for preventing damage and fire hazards caused by electrical overloads and short circuits.
Equipped with thermal magnetic tripping mechanism ensuring fast response to overcurrent. Instantaneous break time for quick circuit interruption. Toggle switch reset actuator allows easy manual resetting. Screw terminals for secure and stable wiring connections.
Compact size with dimensions 80mm depth and 66mm width suitable for DIN rail mounting. Breaking capacity of 10kA for handling significant fault currents. IP20 rating making it touch-safe during operation. Operational temperature range from -25°C to +75°C for use in harsh environments.
Mechanical life rated at 10,000 operations ensuring durability and long service life.
This Eaton FAZ-D1/1 miniature circuit breaker is a trusted choice for efficient and effective circuit protection across diverse electrical applications. Explore more electrical protection devices in the MCB category on EnvMart to find solutions tailored to your needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 1A, making it suitable for low current applications.
It features a breaking capacity of 10 kA, which allows it to safely interrupt significant fault currents.
It is designed for use with both 240V AC and 48V DC electrical systems, providing versatility in applications.
It includes a toggle switch reset actuator that allows for easy manual resetting after a trip event.
It employs a thermal magnetic tripping mechanism, ensuring a fast response to overcurrent conditions.
This unit has compact dimensions of 80 mm in depth and 66 mm in width, making it suitable for confined spaces.
It has an IP20 rating, which provides protection against accidental contact with live parts.
It features screw-type terminals that ensure secure and stable wiring connections.
It operates effectively within a temperature range of -25°C to +75°C, suitable for harsh environments.
This is a 1-pole circuit breaker, designed for single-phase applications.
It is rated for a mechanical life of 10,000 operations, ensuring reliability over extended use.
This model is part of the xEffect series, which is known for its efficient circuit protection features.
