ABB Residual Current Circuit Breaker with Overload Protection 10A Current Rating 2CSR255051R1104 DSE201 C10 AC30 - N Blue

ABB 2CSR255051R1104 DSE201 C10 AC30 - N Blue Residual Current Circuit Breaker combines overload and earth leakage protection to ensure comprehensive electrical safety in industrial and commercial installations. With a 10A current rating and 1-pole configuration, this breaker caters to standard electrical circuits requiring sensitive 30 mA trip threshold to detect earth leakage.

The DSE201 series breaker is part of ABB's System Pro M Compact range, engineered for reliable performance with a breaking capacity of 6 kA. Its Type C tripping characteristics and thermal magnetic mechanism provide fast and accurate interruption during overloads and short circuits, effectively protecting electrical wiring and connected devices.

Mount type is DIN Rail compatible with screw terminals, facilitating secure and straightforward installation. The device's toggle switch reset actuator enables manual resetting, while color-coded contact indicators enhance operational safety by clearly showing circuit status.

The unit is housed in an IP20-rated enclosure to prevent access to hazardous parts by fingers or objects larger than 12.5mm, reinforcing user protection. Its dimensions (100mm height, 17.6mm width, 68.9mm depth) and lightweight design (approx. 180g) ensure it fits standard electrical panels without occupying excessive space.

This breaker operates reliably within a temperature range of -25°C to +55°C, making it suitable for diverse environments including industrial controls, telecommunication systems, and critical medical equipment installations.

Applications include protection of electrical installations from short circuits, overload, and earth leakage currents, maintaining operational integrity and safety of sensitive equipment.

This breaker includes overload protection to safeguard circuits from excess current. Designed with a Type C tripping characteristic suitable for general applications. Mounts easily on DIN Rails with a screw terminal type for reliable connections.

Equipped with thermal magnetic tripping mechanism and toggle switch reset actuator. Comes in a compact size with 100mm height and 17.6mm width to fit standard enclosures. Breaking capacity of 6 kA ensures capability to interrupt high fault currents safely.

Rated for 240V AC operation with AC earth leakage protection type for installation safety. Lightweight at 180g and includes color-coded contact position indicators for enhanced safety. IP20 rated casing protects against touch and ingress of objects larger than 12.5mm.

Operating temperature range from -25°C to +55°C supports demanding environments.

Ensure compliance and enhanced safety in your electrical installations with this ABB RCBO from the System Pro M Compact range. Browse EnvMart’s extensive selection of circuit breakers and electrical safety devices for industrial and commercial applications.
