Weidmüller Panel Power Relay 115V ac Coil Voltage 5A Switching Current 4PDT DRM Series 7760056085
Specifications
| Country of Origin | China |
|---|---|
| Brand | Weidmüller |
| Height | 28mm |
| Length | 21.5mm |
| Width | 36mm |
| Mount Type | Panel |
| Contact Material | Silver Alloy |
| Series | DRM |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | 4PDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 5A |
| Terminal type | Plug-In |
| Standards/Approvals | cURus |
| Coil Resistance | 4340Ω |
| Coil Voltage | 115V ac |
| Switching AC Voltage | 250V ac |
Key Features
- Equipped with a 115V AC coil ensuring reliable operation in control circuits.
- Features a 4PDT (four-pole double throw) contact configuration for flexible switching.
- Can switch up to 5A current and withstand up to 250V AC voltage on contacts.
- Compact DRM series design ideal for panel mounting with plug-in terminals.
- Operates efficiently within a temperature range from -40°C to 55°C.
- Constructed with silver alloy contact material for enhanced durability and conductivity.
- Includes coil resistance of 4340Ω ensuring stable coil performance.
- Certified with cURus standards for safety and compliance.
Product Description
Weidmüller 7760056085 Panel Power Relay is engineered for demanding industrial environments requiring reliable switching performance. This relay features a 115V AC coil voltage suitable for controlling actuators and industrial equipment with voltages ranging between 110 and 220 V. It is part of the DRM series, known for durable design and long service life.
The relay has a 4PDT contact arrangement which offers four double throw contacts, allowing multiple switching operations. It supports a switching current of 5A and can withstand switching AC voltages up to 250V. Its silver alloy contacts provide excellent conductivity and resistance to wear and arcing.
Designed for panel mounting, the relay includes plug-in terminals facilitating easy installation and replacement on control panels. Its compact dimensions of 21.5mm length, 36mm width, and 28mm height provide space-efficient integration in electrical assemblies.
Operating temperatures range from -40°C to 55°C, enabling usage in various industrial and environmental conditions. The coil resistance of 4340Ω ensures consistent coil performance and electrical characteristics.
Certified to meet cURus standards, this power relay complies with relevant safety and quality requirements, making it suitable for industrial automation, electrical panel control, HVAC systems, and manufacturing applications.
Reliable 115V AC coil operation for industrial control signals. 4PDT contact configuration enables complex switching functions. High switching current capacity of 5A for varied loads. Compact panel mount design with plug-in terminals for ease of use.
Durable silver alloy contacts resist arcing and wear. Wide operating temperature range for diverse environments. Stable coil resistance ensures reliable coil function. Certified to cURus standards for industrial safety compliance.
Weidmüller Power Relays are ideal for integration in control panels of industrial machinery, automation systems, and electrical distribution equipment. Browse EnvMart's extensive Weidmüller inventory and related power relay solutions for your technical and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a coil voltage of 115V AC, making it suitable for controlling various industrial equipment.
It can switch a maximum current of 5A, allowing for versatile applications in control circuits.
This relay features a 4PDT (four-pole double throw) contact configuration, enabling multiple switching operations.
It can withstand switching AC voltages up to 250V, which is suitable for various industrial applications.
The relay operates efficiently within a temperature range from -40°C to 55°C, making it adaptable to different environments.
The contacts are constructed from silver alloy, providing enhanced conductivity and durability.
It is designed for panel mounting and includes plug-in terminals for easy installation and replacement.
The coil resistance is 4340Ω, which ensures stable coil performance during operation.
It is certified with cURus standards, ensuring compliance with relevant safety and quality requirements.
The dimensions are 21.5mm in length, 36mm in width, and 28mm in height, allowing for compact integration into electrical assemblies.
This power relay is suitable for industrial automation, electrical panel control, HVAC systems, and manufacturing applications.
It is part of the DRM series, known for its durable design and long service life in industrial environments.
