NSK Linear Guide Rail 20 mm Width 400 mm Length Carbon Steel Material N1H200400LCN-PCZ

The NSK N1H200400LCN-PCZ Linear Guide Rail is a precisely engineered component designed for industrial linear motion requirements. This product features a 20 mm wide rail with a length of 400 mm, crafted from high-quality carbon steel to provide excellent strength and durability in demanding mechanical applications.

This model is part of the advanced N1H series, which delivers 1.3 times the dynamic load capacity of the older LS and LH series. The innovative groove design enhances the lifespan by increasing the contact area between the ball and rail slide and dispersing load forces, resulting in reduced surface pressure and prolonged maintenance intervals.

The linear guide rail maintains identical installation dimensions with previous LH and LS ranges, ensuring seamless compatibility for retrofitting and upgrades. The redesigned ball recirculation system also improves suitability for high-speed operations while lowering operational noise by up to 3 dB, enhancing workplace conditions.

NSK offers the option of the K1 lubrication system, a maintenance-free solution utilizing a unique mixture of mineral oil and polyolefin resin. This lubrication technology supports linear motion systems to operate up to 40,000 km without the need for additional servicing, making it ideal for environments where grease application is challenging or contamination risks exist.

Typical industrial applications include machine tools, robotics, automotive production lines, semiconductor manufacturing, CT scanners, measuring instruments, automation systems, and train platform doors. The reliable performance and compatibility make this linear guide rail a preferred choice in precision mechanical assemblies.

Constructed from durable carbon steel material ensuring long service life. Part of the N1H series offering 1.3 times dynamic load rating compared to previous LS and LH series. Dynamic load rating of 18.8 kN and static load rating of 32,500 N for high-performance applications.

Compatible with existing LH and LS linear guide components due to identical installation dimensions. New groove design doubles life expectancy by increasing contact area and reducing surface pressure. Improved ball recirculation path reduces noise up to 3 dB, ideal for precision machinery.

Incorporates NSK's optional K1 lubrication system for maintenance-free linear motion up to 40,000 km. Suitable for applications in machine tools, robotics, semiconductor production, and automation industries. Explore more NSK products and industrial Linear Guide Rails at EnvMart for precision and reliability in your machinery applications.
