Murata Power Solutions Series 1W Through Hole DC/DC Converter, 3.3V DC Output, 300mA, 4.75V - 5.25V Input Voltage, 1kV MEF1
Specifications
| Country of Origin | China |
|---|---|
| Brand | Murata Power Solutions |
| Efficiency | 68.5% |
| Length | 19.65mm |
| Model | MEF1 |
| Depth | 10.15mm |
| Gross Weight | 1.6g |
| Width | 19.65mm |
| Mount Type | Through Hole |
| Series | MEF1 |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 30mV Pk-Pk |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 5.25V dc |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 4.75V |
| Number of Pins | 6 |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 300mA |
| Isolation Voltage | 1kV dc |
Key Features
- Fully encapsulated through hole DIP package ensuring ease of installation.
- High efficiency converter with 68.5% typical efficiency at full load.
- Provides single output voltage of 3.3V DC at 300 milliamp current.
- Supports input voltage range from 4.75V to a maximum of 5.25V DC.
- Maintains output voltage regulation better than 1% for stable performance.
- Isolation voltage of 1kV DC to protect circuits from high voltage spikes.
- Compact dimensions with 19.65mm length and width, and 10.15mm depth.
- Ripple and noise limited to 30mV peak-to-peak for clean output signal.
Product Description
Murata Power Solutions MEF1S0503SPC is a reliable 1 watt DC/DC converter designed to provide a stable 3.3V DC output voltage at 300mA output current. Packaged in a compact through-hole DIP format, it measures 19.65mm by 19.65mm with a depth of 10.15mm, making it suitable for space-constrained applications. The device offers a nominal input voltage range from 4.75V to 5.25V DC, making it flexible for various power sources.
This converter is engineered to operate efficiently with a typical efficiency of 68.5%. It features very low output ripple and noise of 30mV peak-to-peak, ensuring high-quality power delivery to sensitive electronics. The unit incorporates 1kV DC isolation between input and output, providing protection against voltage transients and enhancing safety in industrial environments.
The MEF1S0503SPC model supports a wide operating temperature range from -40°C up to 85°C, suitable for demanding industrial, instrumentation, and automotive applications. Its fully encapsulated construction with UL94V-0 flame retardant material ensures durability and reliability under challenging thermal conditions.
This converter is ideal for powering sensors such as pressure transducers, Hall Effect sensors, and mass airflow sensors where precise and regulated supply is critical. Its single isolated output and short circuit protection features enable robust performance in control and measurement systems.
The product complies with RoHS regulations and is part of the MEF1 series known for compact footprint and dependable power conversion. It is through-hole mounted, supporting easy PCB integration.
Fully encapsulated DIP through-hole package. Single output voltage at 3.3V DC and 300mA current. Input voltage range from 4.75V to 5.25V DC. Power rating of 1 watt. Isolated input to output at 1kV DC for enhanced safety.
Maximum operating temperature of 85°C with industrial-grade reliability. Low ripple and noise for sensitive applications. Typical efficiency of 68.5%. RoHS compliant and flame retardant UL94V-0 package. Compact dimensions of 19.65x19.65x10.15mm suitable for dense circuit layouts.
Murata Power Solutions MEF1S0503SPC DC/DC converter is used extensively in industrial electronics, instrumentation, control systems, and power management applications where compact size, isolation, and dependable voltage regulation are essential. Browse more solutions from Murata in the DC/DC Converters category at EnvMart for advanced power supply needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The converter provides a single output voltage of 3.3V DC with a maximum output current of 300mA.
It supports an input voltage range from 4.75V to a maximum of 5.25V DC.
This DC/DC converter has a typical efficiency of 68.5% at full load.
The converter measures 19.65mm in length, 19.65mm in width, and has a depth of 10.15mm.
The maximum operating temperature is 85°C, making it suitable for various industrial applications.
It has a ripple and noise specification limited to 30mV peak-to-peak, ensuring a clean output signal.
This model is designed for through-hole mounting, facilitating easy PCB integration.
The isolation voltage is 1kV DC, providing protection against high voltage spikes.
It complies with RoHS regulations, ensuring it meets environmental standards.
The minimum operating temperature is -40°C, allowing it to function in extreme conditions.
This model features a single output, making it straightforward for various applications.
It is ideal for powering sensors such as pressure transducers and Hall Effect sensors, where regulated supply is critical.
