Murata Power Solutions 2W Dual Output Isolated DC/DC Converter, 21.6V dc, 26.4V dc Input, 40mA Output Current, 5V MGJ2

Murata Power Solutions MGJ2 is a 2W dual output isolated DC/DC converter designed primarily for use in electronic circuits requiring reliable and efficient power supply solutions. Featuring precise input voltage operation from 21.6V to 26.4V DC, this device provides an output current of 40mA at a regulated 5V output, making it suitable for powering high side and low side gate drive circuits in bridge circuits for IGBTs and MOSFETs.

This converter is housed in a DIP package optimized for PCB mounting with dimensions of 19.65mm length, 19.5mm width, and 12.65mm depth, fitting compact system designs. It supports an operating temperature range from -40°C to 100°C, ensuring reliable performance in industrial and demanding environments. The MGJ2 series is characterized by a high isolation voltage of 5.2kV DC, providing excellent protection and reducing interference in critical applications.

The device’s 82% efficiency helps reduce energy losses and thermal issues. Furthermore, it meets RoHS compliance and is built to withstand characteristically high dv/dt stress while maintaining partial discharge immunity, enhancing device reliability and lifespan. Its footprint of 1.96cm² and SIP package style make it a space-efficient power solution.

This DC/DC converter is especially prevalent in industrial automation, motor drives, inverter circuits, and power management applications in electronics and electrical systems. The MGJ2 provides optimized bipolar output voltages advantageous for system efficiency and EMI performance.

In summary, the Murata Power Solutions MGJ2 DC/DC converter is an advanced power device delivering efficient dual-output voltage with high isolation, compact form factor, and rugged reliability suited for demanding industrial and electronic applications.

Operates with an input voltage range from 21.6V to 26.4V DC. Provides dual output voltages with 40mA output current and 5V secondary output. Offers a maximum output power of 2 watts for efficient power delivery. Features high isolation voltage of 5.2kV DC suitable for industrial applications.

Encased in a compact DIP package with dimensions optimized for PCB mounting. Supports operation in wide temperature range from -40°C to 100°C ensuring robustness. Offers 82% efficiency contributing to low power loss and heat generation.

Certified to RoHS standards for environmental compliance. Ideal for powering gate drive circuits in bridge circuits for IGBTs and MOSFETs. Designed to handle dv/dt immunity and partial discharge performance for long-term reliability.
