Murata Power Solutions 1W Single Output Regulated Isolated DC/DC Converter 5V 200mA 9-36V Input Through Hole DIP Package NCS1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters Murata Power Solutions NCS1 DC/DC Converter, 5V/ 2 |
| Brand | Murata Power Solutions |
| Efficiency | 80% |
| Length | 21.87mm |
| Model | NCS1 |
| Depth | 11.3mm |
| Gross Weight | 3.3g |
| Width | 21.87mm |
| Mount Type | Through Hole |
| Series | NCS1 |
| Maximum Operating Temperature | 105°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 24mV Pk-Pk |
| Maximum Output Power | 1W |
| Maximum Input Voltage | 36V dc |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 9V |
| Number of Pins | 6 |
| Output Voltage 1 | 5V |
| Output Current 1 | 200mA |
| Isolation Voltage | 1kV dc |
Key Features
- Wide input voltage range from 9V to 36V DC ensures flexible power supply compatibility.
- Provides a regulated isolated 5V output voltage with 200mA maximum current.
- Encapsulated DIP package provides superior thermal performance and ease of installation.
- High isolation voltage of 1kV DC protects sensitive electronics from voltage spikes.
- Operating temperature range from -40°C to 105°C supports rugged industrial environments.
- Low output ripple and noise of 24mV peak-to-peak ensures stable power delivery.
- High efficiency of approximately 80% reduces power loss and thermal buildup.
- Continuous short circuit protection enhances system reliability and safety.
Product Description
Murata Power Solutions NCS1 NCS1S2412SC DC/DC Converter is a compact, high-performance isolated power converter delivering 1 watt of output power. It provides a stable regulated single output of 5 volts at 200 milliamps, with wide input voltage support ranging from 9 volts to 36 volts DC. The module's through hole DIP package is encapsulated for superior thermal management and reliability in various electrical and electronic applications.
This converter offers excellent isolation of 1kV DC between input and output, making it suitable for telecommunications, battery-powered instruments, distributed power architectures, and industrial process control systems where safety and noise isolation are essential. Its operating temperature range from -40°C to 105°C enables use in harsh environments.
The NCS1 series features low output ripple and noise (24 mV peak-to-peak) and continuous short circuit protection, ensuring reliable and robust operation. The device follows industry standard pinouts facilitating seamless PCB layout integration and replacement.
Wide 9 - 36 V DC input voltage range for versatile deployment. Isolated regulated single 5 V output with 200 mA maximum current. Encapsulated through hole DIP package with 6 pins enhances durability and thermal performance.
1 kV DC isolation voltage protects sensitive downstream components. Operating temperature from -40°C to 105°C for demanding industrial use. 24 mV peak-to-peak output ripple for clean power delivery. 80% efficiency minimizes power dissipation and heat generation.
Continuous short circuit protection ensures safety under fault conditions. RoHS compliant with environmentally friendly manufacturing standards.
This DC/DC Converter is ideal for industrial, telecommunications, power management, and instrumentation applications where compact size, electrical isolation, and stable output power are critical. The series supports a broad range of uses from battery-powered equipment to distributed power systems requiring clean isolated power rails.
Explore more high-quality power solutions in the Murata Power Solutions range and discover reliable components engineered for professional and industrial electronics designs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 9V to 36V DC.
It provides a maximum output current of 200mA.
The output voltage is regulated at 5V.
This converter has an isolation voltage of 1kV DC, protecting sensitive electronics from voltage spikes.
The efficiency of this unit is approximately 80%.
The dimensions are 21.87mm in length, 11.3mm in depth, and 21.87mm in width.
It operates within a temperature range of -40°C to 105°C.
This model comes in an encapsulated DIP package, suitable for through-hole mounting.
The output ripple and noise is specified at 24mV peak-to-peak.
It includes continuous short circuit protection to enhance system reliability and safety.
Yes, the device is RoHS compliant, adhering to environmentally friendly manufacturing standards.
This converter is suitable for telecommunications, battery-powered instruments, and industrial process control systems.
