TDK-Lambda HWS50A-5 Switching Power Supply 5V DC 50W 370V DC 265V AC Chassis Mount HWS50A-5

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda HWS50A-5 Switching Power Supply 5V DC 50W 370V DC 265V AC Chassis Mount HWS50A-5

Name: TDK-Lambda HWS50A-5 Switching Power Supply 5V DC 50W 370V DC 265V AC Chassis Mount HWS50A-5
Brand: TDK-Lambda
SKU: 375973
Price: 20.22 USD
Availability: InStock



Category Switching Power Supply Brand TDK-Lambda Condition New

Specifications

Country of Origin	Malaysia
Brand	TDK-Lambda
Power	50W
Efficiency	87%
Length	82mm
Model	HWS50A-5
Depth	120mm
Gross Weight	280g
Width	26.5mm
Mount Type	Chassis
Series	HWS50A
Maximum Operating Temperature	50°C
Minimum Operating Temperature	-10°C
Number of outputs	1
Maximum Input Voltage	370, 265V dc
Standards/Approvals	CE, EN 50178, EN 55011 / EN 55022, FCC VCC, HWS1500: Class A, IEC 61000-4-2, IEC/EN/UL/CSA 60950-1 and 62368-1, UL 508, SEMI-F47
Maximum Output Voltage	5V dc
SMPS Output Current	10A
Minimum Input Voltage	85V ac
Standards/Approvals CE, EN 50178, EN 55011 / EN 55022, FCC VCC, HWS1500	Class A, IEC 61000-4-2, IEC/EN/UL/CSA 60950-1 and 62368-1, UL 508, SEMI-F47

Key Features

Provides a maximum output voltage of 5V DC with 10A output current capacity.
Operates from a wide input voltage range of 85V AC to 265V AC and up to 370V DC maximum input voltage.
Features chassis mounting type for secure installation.
Designed to work in temperature range from -10°C to 50°C at full load and tolerates up to 70°C with derating.
Compact dimensions of 82mm length, 26.5mm width, and 120mm depth ensure space-saving fitment.
Lightweight at 280 grams with high efficiency of 87% for energy savings.
Meets multiple international standards and certifications including CE, EN 50178, EN 55011, FCC VCC, IEC/EN/UL/CSA 60950-1, UL 508, and SEMI-F47.
Suitable for factory automation, process control, LED display, test and measurement, broadcast and communications equipment.

Product Description

TDK-Lambda HWS50A-5 Switching Power Supply 5V DC 50W chassis mount unit designed for robust industrial power applications requiring reliable DC output.

This power supply offers a single output of 5 volts direct current with a maximum output current of 10 amperes, powering devices efficiently with an output power rating of 50 watts.

It accepts a universal input voltage range from 85 to 265 volts AC and can also handle DC inputs up to 370 volts, making it suitable for diverse global power conditions.

Constructed as a chassis-mount model with compact dimensions of 82mm length, 26.5mm width, and 120mm depth and weighing only 280 grams, it facilitates easy installation and integration into control panels and industrial systems.

The device operates reliably over an extended temperature range from -10°C to +50°C at full load, and up to +70°C with derating, ensuring stable performance in demanding environments.

High efficiency of 87% ensures minimal power loss and heat generation, complemented by active power factor correction which is included in the 50W model and above, enhancing energy savings and compliance with regulatory requirements.

This power supply complies with numerous international safety and electromagnetic compatibility standards such as CE, EN 50178, EN 55011 / EN 55022, FCC VCC, IEC/EN/UL/CSA 60950-1 and 62368-1, UL 508, and SEMI-F47 standards, tested for industrial usage scenarios.

Typical use cases include factory automation, process control, LED display and signage, test and measurement equipment, broadcast, and communications infrastructure. Maximum output voltage of 5V DC and output current of 10A.

Universal AC input voltage range 85-265V AC and max 370V DC input voltage support. Compact chassis mount form factor with dimensions 82 x 26.5 x 120 mm. Operating temperature from -10°C to 50°C at full load, tolerates up to 70°C with derating.

87% efficiency and active power factor correction included. Conforms to CE, EN 50178, FCC, UL, SEMI-F47 and other safety and EMC standards. Lightweight design at 280 grams for easy panel integration. Manufactured in Malaysia under stringent quality standards.

Ideal for industrial power supply applications including automation, measurement, and communication devices. Explore the extensive range of industrial power supplies in the Electronics & Electricals category at EnvMart for unmatched reliability and performance.
