Microchip 8-bit PIC Microcontroller, 32 MHz Clock, 7kB Flash Memory, 44-Pin TQFP PIC16F1784-I/PT

Microchip PIC16F1784-I/PT is an 8-bit microcontroller built on Microchip's enhanced mid-range PIC core architecture. It operates at a maximum clock frequency of 32 MHz with a 7kB flash program memory and 512-bit RAM, making it well suited for embedded systems requiring low power consumption and high performance.

This microcontroller comes in a 44-pin TQFP surface mount package measuring 10mm x 10mm x 1.05mm, providing a compact footprint for space-conscious designs. The device supports multiple communication interfaces including SPI, I2C, and EUSART, facilitating connectivity across various industrial and consumer applications.

Equipped with up to 36 programmable I/O pins, it offers flexibility for controlling peripherals and interfacing with other devices. The inclusion of 14 channels of 12-bit ADC and a single 8-bit DAC allows precise analog input and output processing. Additional on-chip features include multiple timers, operational amplifiers, comparators, and low-voltage programming support.

The PIC16F1784 incorporates energy-efficient XLP technology for reduced power consumption, alongside safety features such as Power-On Reset (POR), Power-Up Timer (PWRT), Brown-Out Reset (BOR), and an Extended Watchdog Timer (WDT) to enhance system reliability in challenging industrial and laboratory environments.

This device is RoHS compliant, meeting environmental regulations for hazardous substances. Its operating temperature range from -40°C to 85°C makes it suitable for harsh industrial conditions and automotive applications.

Operates with 8-bit PIC architecture for reliable embedded applications. Supports SPI, I2C, and EUSART interfaces for versatile communication options. Includes 512-bit RAM and a maximum power dissipation of 800mW. Features up to 36 programmable I/O pins and 14 channels of 12-bit ADC.

Designed with enhanced mid-range core providing up to 8 MIPS performance. Operates within temperature range of -40°C to 85°C for industrial reliability. Comes in a compact 10mm x 10mm x 1.05mm TQFP surface mount package.

Includes onboard peripherals such as DAC, operational amplifiers, timers, and comparators. Energy-saving XLP technology and features like Power-On Reset and Brown-Out Reset improve stability. RoHS compliant and suits applications in industrial, laboratory, and embedded system environments.

This microcontroller is ideal for a wide range of applications including industrial control systems, automotive electronics, consumer devices, and instrumentation. Its robust feature set combined with compact packaging facilitates efficient product design and system integration. Browse more Microchip Microcontrollers and semiconductor products at EnvMart.
