RS PRO Pressure Sensor, Current Output, Gauge Reading, -1 bar to 24 bar Measurement 797-4999

Free Delivery in India | Lowest Global Shipping Charges

RS PRO Pressure Sensor, Current Output, Gauge Reading, -1 bar to 24 bar Measurement 797-4999

Name: RS PRO Pressure Sensor, Current Output, Gauge Reading, -1 bar to 24 bar Measurement 797-4999
Brand: RS PRO
SKU: 372549
Price: 277.61 USD
Availability: InStock



Category Pressure Sensor Brand RS PRO Condition New

Specifications

Country of Origin	China
Accuracy	±0.25 %
Brand	RS PRO
Model	797-4999
IP Rating	IP65
Mount Type	Threaded
Housing Material	Stainless Steel
Output type	Current
Series	RS PRO
Maximum Operating Temperature	135°C
Minimum Operating Temperature	-20°C
Terminal type	DIN
Standards/Approvals	CE EMC directive EN 61326-1:2013
Maximum Pressure Measurement	24bar
Minimum Pressure Measurement	-1bar
Maximum Supply Voltage	32V dc
Minimum Supply Voltage	9V
Pressure Reading Type	Gauge
Media Measured	Air, Gas, Hydraulic Fluid, Liquid, Water
Standards/Approvals CE EMC directive EN 61326-1	2013
RS PRO Pressure Sensor, -1bar Min, 24bar Max, Analogue OutputBrand	RS PRO

Key Features

Compact stainless steel housing ensures ruggedness and durability.
Piezo-resistive ceramic sensor for excellent media compatibility.
Suitable for air, gas, hydraulic fluid, liquid, and water measurements.
High accuracy of ±0.25 percent for precise pressure readings.
DIN terminal type with a 4-pin M12 connector for easy installation.
Operating temperature range from -20°C to 135°C fits varied applications.
IP65 rated for protection against dust and water jets.
Flexible installation with threaded mount type BSP 1/4.

Product Description

RS PRO 797-4999 Pressure Sensor offers reliable current output signal with gauge pressure reading from -1 bar minimum to 24 bar maximum. The device is housed in a rugged stainless steel 316L casing, protected with Viton O-ring seals and a ceramic Al2O3 diaphragm for excellent durability and chemical resistance.

It employs a piezo-resistive thick film ceramic sensor ensuring high precision and excellent media compatibility, enabling its use in measuring air, gas, hydraulic fluids, liquids, and water in demanding industrial, process control, and automation environments.

The sensor operates with a minimum supply voltage of 9V and a maximum of 32V DC, featuring DIN terminal connections and a threaded BSP 1/4 mount. Its IP65 rating protects it against dust ingress and water jets, extending its applicability in harsh environments.

Designed to operate across a temperature range of -20°C to 135°C, it guarantees high accuracy of ±0.25 percent and a long operational life spanning over 100 million cycles, with insulation resistance exceeding 50M Ohms at 50V DC.

Compact and rugged design with stainless steel housing. Suitable for diverse media including air, gas, liquid, and hydraulic fluids. High-accuracy piezo-resistive ceramic sensing technology. Threaded BSP 1/4 mount and DIN terminal connector for ease of installation.

Compliant with CE EMC directive EN 61326-1:2013 for enhanced electrical safety. Wide temperature operating range and IP65 protection level. Long lifecycle and excellent electrical insulation ensure reliability.

This Pressure Sensor is ideal for industrial, automation, process control, temperature testing facilities, and other demanding measurement applications. With its robust construction and certified standards, it assures dependable performance for engineers and technicians.

Explore the RS PRO range for quality industrial sensors and measuring instruments tailored to professional requirements. EnvMart offers comprehensive solutions to meet diverse industrial measurement needs.
