NSK-RHP Bearing Insert 20 mm ID 28.3 mm OD Cast Iron 6.65kN Static Load 12.8kN Dynamic Load 1220-20G

NSK-RHP 1220-20G Bearing Insert is a high-quality rotary bearing component designed for industrial, mechanical, and manufacturing applications where precise shaft support and reliable bearing performance are critical. Featuring a 20 mm inside diameter and 28.3 mm outside diameter, this cast iron bearing insert provides robust structural stability and durability.

The bearing is secured onto shafts using a set screw locking mechanism, which ensures firm attachment during operation. This type of locking is suitable for applications requiring precise axial positioning while allowing for easy installation and removal.

With a static load rating of 6.65 kN and a dynamic load rating of 12.8 kN, the 1220-20G bearing insert is capable of handling both stationary and rotational loads effectively. Its limiting speed of 6700 rpm supports high-speed rotational machinery.

The cylindrical bore design offers versatility in mounting, making it compatible with various housings and shaft types. The overall width of 25.8 mm allows for installation in compact spaces without compromising on load capacity.

This bearing is part of the 1000G series and does not carry additional certification approvals but meets stringent industry requirements for quality and reliability. It is ideal for use in industrial, manufacturing, fluid power, and mechanical machinery settings requiring self-lubricated sealed bearing units or customized housing solutions.

Inside diameter of 20 mm for precise shaft fitting. Outside diameter of 28.3 mm for housing compatibility. Constructed from durable cast iron material. Static load rating of 6.65 kN supports stationary loads. Dynamic load rating of 12.8 kN enables effective rotational load handling.

Set screw locking provides secure shaft attachment. Cylindrical bore type for flexible mounting. Overall width measures 25.8 mm suitable for compact assemblies. Limiting speed up to 6700 rpm for high-speed applications. 1000G series quality standard.

Manufactured in the United Kingdom assuring product quality.

Choose this NSK-RHP Bearing Insert for reliable performance in industrial, laboratory, manufacturing, HVAC, and mechanical applications requiring precision bearing solutions. Explore more bearings and housing units in the EnvMart Rotary Bearings & Housing Units category for complementary products.
