Finder Monitoring Relay 1 Phase SPDT DIN Rail Mount 24V AC DC 1.5W Power Consumption 72.01.8.125.0000

Finder 72.01.8.125.0000 Monitoring Relay is a compact 1 phase electrical control device designed for level monitoring with a single-pole double-throw (SPDT) contact configuration. It supports DIN rail mounting and operates on 24V AC or DC supply voltage with a power consumption of 1.5W. This relay is suitable for various industrial applications requiring monitoring and control of liquid levels and pump operations.

The device features adjustable sensitivity allowing accurate detection of liquid conductivity, enabling precise control in applications such as swimming pool management, bottling plants, and industrial washing machines. The selectable time delay from 0.5 to 7 seconds improves operational flexibility for different process needs.

Constructed with screw-type terminals and rated at a contact current of 16A and switching voltage of 400V, it is engineered for durability and reliable performance. Its IP20 rating provides protection against solid foreign objects, making it suitable for indoor industrial environments. The relay can withstand ambient temperatures from -20°C up to +60°C, ensuring robust operation under various environmental conditions.

The compact size of 58mm length, 35mm width, and 84mm height facilitates easy installation on DIN rails in control panels. Certified under RoHS, it meets critical environmental and safety standards. This monitoring relay is widely employed in industrial automation, process control, and water treatment systems where precise level detection and pump control are essential.

Adjustable sensitivity enables fine-tuning for accurate level detection. Select delay time from 0.5 to 7 seconds to suit application requirements. Low power consumption of 1.5 watts ensures energy efficiency. Supports high contact current of 16 amperes at 400 volts switching voltage.

Screw terminal type guarantees secure electrical connections. IP20 protection rating for safety in standard industrial environments. Wide operating temperature range from -20°C to +60°C for versatility. Compact dimensions allow easy DIN rail installation.

RoHS compliant for environmental and safety standards. Applicable in swimming pool control, bottling, milk processing, pump control, and industrial washing systems.

This product is an ideal component for industrial, laboratory, manufacturing, and water treatment applications requiring reliable monitoring relays. Browse EnvMart for more Monitoring Relays and electrical control devices from trusted brands.
