RS PRO Non-Resettable Fuse Radial 100mA 250V ac Time Delay Thermoplastic Body 767-5002

RS PRO 767-5002 Non-Resettable Fuse Radial 100mA 250V ac is an industrial-grade electrical fuse designed for effective circuit protection in various applications including industrial, laboratory, and automation systems. The fuse uses a time delay (slow blow) characteristic to tolerate momentary surges without premature failures, making it ideal for sensitive electrical equipment.

The fuse body is constructed from a black thermoplastic (Polyamide) material rated UL 94-V0, ensuring excellent electrical insulation and flame retardance. It features round tin-plated copper pins with radial lead orientation measuring 22mm in length, ensuring easy mounting and reliable electrical connection.

Designed to operate within temperatures ranging from -55°C to 125°C, it suits harsh operating environments. The fuse has a breaking capacity of 35A, enabling it to safely interrupt fault currents and prevent equipment damage. Compliance with RoHS and CSA standards guarantees that the product meets stringent quality and environmental directives.

Tested for vibration resistance according to MIL-STD-202G Method 201 and salt spray resistance per MIL-STD-202G Method 101, it ensures durability in challenging industrial environments. Additional tests like insulation resistance, resistance to solder heat, and thermal shock validate its robustness and long service life.

Overall, the RS PRO 767-5002 fuse offers a reliable, certified, and high-quality solution for circuit protection demands in electronics, electrical automation, and control systems. Its compact size and radial lead design facilitate diverse applications including control gear, automation panels, and power supply safeguarding.

The fuse features a 100mA current rating with a 250V alternating voltage. It has a radial lead orientation with 22mm lead length for easy installation. The body material is thermoplastic providing durability and insulation.

Time delay fuse characteristic is designed for slow blow usage. Operating temperature ranges from -55°C minimum to 125°C maximum ensuring wide application. Breaking capacity is rated at 35A to handle fault currents safely.

Compact dimensions: length 8.35mm, width 4.3mm, height 7.7mm, and a 0.62mm diameter lead. Compliance with RoHS and CSA standards ensures quality and safety adherence. Manufactured in Taiwan, Province Of China, reflecting precise production quality.
