Igus Chainflex CF130.UL Control Cable, 5 Cores, 1mm² 17 AWG, Unscreened, Armoured, 25 m Length, Grey CF130.10.05.UL

Igus CF130.10.05.UL Chainflex Control Cable is engineered to meet medium load requirements in industrial automation, signaling, and control environments.

This 5-core cable with 1mm² (17 AWG) stranded bare copper conductors ensures efficient and consistent electrical transmission. The unscreened design is ideal for applications where shielding is not mandatory, enhancing flexibility and ease of installation.

The grey thermoplastic elastomer outer sheath provides excellent resistance against oils, abrasion, and mechanical stress. The cable is armoured, offering superior mechanical protection suitable for settings with potential physical impacts.

Operating voltage ratings are 300 and 500 volts with a temperature tolerance from -5°C to 70°C, making it reliable across a wide range of industrial conditions. Flame retardant properties conform to IEC 60332-1-2 and CEI 20-35 standards enhance safety in case of fire.

Its design supports freely suspended travel distances and high torsion resistance, rendering it suitable for use in energy chains and dynamic applications where movement is frequent up to 50 meters.

The outer sheath is a specialized low-adhesion PVC mixture adapted to Energy Chains® requirements per DIN VDE 0282 Part 10, ensuring reduced friction and longer cable life.

Compliant with EN and CE standards, this cable is a dependable choice for electrical power and industrial control wiring in laboratories, manufacturing, water treatment, HVAC systems, and other industrial automation sectors.

The cable features a grey thermoplastic elastomer sheath for durable protection. It is armoured to enhance mechanical robustness and suitable for demanding environments. Designed for medium load applications with torsion resistance and flame retardant properties.

Operating voltage ratings of 300V and 500V with temperature range from -5°C to 70°C. The conductor consists of stranded bare copper wires for optimal conductivity. Complies with EN and CE standards, ensuring quality and safety.

Preferred for indoor applications with flame retardant characteristic per IEC 60332-1-2. Suitable for use in energy chains and freely suspended travel distances up to 50 meters. Its outer sheath is a low-adhesion PVC blend meeting DIN VDE 0282 Part 10 requirements.

Manufactured in Germany adhering to stringent industrial quality. Explore the range of industrial Control Cables available on EnvMart for various automation, manufacturing, and power distribution uses.
