ABB Fuse Switch Disconnector 4-Pole 160A DIN Rail Mount OS125GB04N1P 1SCA115901R1001

ABB OS125GB04N1P 1SCA115901R1001 Fuse Switch Disconnector is a high quality 4-pole, 160A rated electrical switching device designed primarily for industrial, electrical automation, and commercial applications. It provides secure short circuit protection combined with circuit isolation, essential in protecting electrical distribution systems and equipment.

This disconnector is designed for DIN rail mounting with flexible adjustable mounting feet allowing top or side installations. The device includes a black plastic ON/OFF handle and an adjustable operating shaft making operation easy and safe. The mechanical fuse sizes A2, A3, and A4 make it compatible with different fuse ratings for tailored circuit protection.

The fuse carrier is protected to IP20 out of the box, but when mounted correctly in a suitable enclosure and using the supplied or optional handle, a front protection rating of IP65 is achieved. This ensures protection against dust and water suitable for harsh industrial environments.

The disconnector supports lug terminal type connections enabling secure cable attachments with low maintenance. Its switching voltage rating is 1000V, switching current 160A, and switching power 132kW, enabling it to handle demanding electrical loads reliably. Additional features include auxiliary contacts for signaling and control integration.

The product complies with various international standards such as IEC 60269-2-1/-6, IEC 60947-3, BS 88-2, DIN 43620, NFC 63210, ensuring safety, reliability, and interoperability. Operating temperature range up to 60°C suits a wide range of industrial environments. The robust design includes lockable handles with test positions enhancing operational safety and ease.

Ideal use cases include electrical and automation installations in manufacturing, industrial plants, HVAC systems, and commercial electrical distribution boards. This Fuse Switch Disconnector from ABB, manufactured in Finland, represents a dependable choice for professionals seeking trusted circuit protection and switching solutions.

Provides 3-phase electrical switch disconnection with neutral pole non-fused functionality. Suitable for DIN rail mounting ensuring easy installation and adjustable mounting feet for versatile mounting options. Features lug terminal connections for secure and reliable wiring interface.

IP3X, IP20 and IP65 rated protection when used with proper enclosure and handle. Mechanical fuse sizes supported include A2, A3, and A4 fuses for various ampere ratings. Switching voltage rating up to 1000V and switching power rating of 132kW for robust industrial applications.

Supports auxiliary contacts for additional control circuit integration. Operates reliably up to maximum temperature of 60°C. Standard compliant with IEC 60269, IEC 60947-3, BS 88-2 and others, ensuring international quality standards.

Manufactured in Finland, ensuring high build quality and reliability. Explore more reliable electrical switch disconnectors and automation components on EnvMart for your industrial and commercial needs.
