Provertha TMC 25 Way Straight 2.84 mm Pitch Through Hole D-Sub Connector with 4 to 40 Screw Lock Male 023158

Provertha 023158 is a 25 Way Straight Through Hole D-Sub Connector designed with a 2.84 mm pitch and male contacts. This connector belongs to the TMC series, known for high reliability and performance in power connector applications.

The connector's housing is constructed from polybutylene terephthalate, providing excellent durability and mechanical strength. It features a through-hole mounting type with 4 to 40 screw lock hardware, ensuring a secure and stable connection to PCBs.

Contacts are gold plated for superior electrical conductivity and corrosion resistance. The connector is rated for a maximum current of 7.5A and can operate in temperatures ranging from -65°C to 125°C, making it suitable for a wide range of industrial environments.

The product supports a voltage rating of up to 1.25 kV, providing reliable electrical performance in demanding applications. It is terminated via soldering and is oriented straight to facilitate integration with various electronic systems.

This D-Sub connector is commonly used in industrial electronics, power distribution equipment, and control systems requiring robust power connectors with consistent pitch and pin spacing.

Provertha's TMC series connectors are available in multiple pin counts and housing sizes, providing flexibility for different design needs. The connector has 25 contacts configured in a straight orientation. It supports a continuous current rating of 7.5A for demanding electronic applications.

The housing is made of durable polybutylene terephthalate material. Connector mounting is through hole with a 4 to 40 screw lock mechanism for secure installation. Operating temperature ranges from -65°C to 125°C for wide environmental adaptability.

Contacts are gold plated to ensure corrosion resistance and excellent conductivity. Termination type is solder with male contact gender for reliable soldered connections. Pitch between contacts measures 2.84 mm, consistent with the TMC series standards.

This D-Sub Connector is designed for industrial and electronic components use cases. Suitable for applications requiring robust, high-voltage connectors up to 1.25 kV. Explore our range of power and electronic connectors at EnvMart to find compatible components and accessories for your projects.
