RS PRO Barrier Strip 5 Contact 5 Row 400V 25A 209-7564

RS PRO 209-7564 Barrier Strip 5 Contact 5 Row is a durable electrical connector designed for medium-duty power and signal distribution in industrial and commercial applications. It operates at a maximum voltage of 400V and a current rating of 25A, making it suitable for a wide range of circuits.

The device features 5 brass contacts that are nickel-plated to ensure excellent electrical conductivity and corrosion resistance. It supports 5 rows of contacts arranged in a straight orientation for ease of wiring and installation. The termination is performed via M4 screws on the top of the unit, facilitating secure and reliable wire connections.

The barrier strip’s body is molded from robust black polycarbonate material that is UL 94 V-0 certified for self-extinguishing characteristics and tolerates operating temperatures ranging from -40°C up to 135°C. The physical size of the unit is compact, measuring 85.3 mm in length, 36 mm in width, and 22 mm in depth, allowing it to fit into tight spaces commonly found in panel-mounted electrical systems.

This product is expressly designed to be mounted using the molded mounting holes at each end of the strip, ensuring firm attachment to the mounting surface and preventing loosening due to vibration or handling. It supports wire sizes up to 16 AWG, ideal for medium current electrical wiring with crimped terminals.

While the barrier strip does not carry official standards or certifications, it is engineered for reliability and versatility in electrical, manufacturing, HVAC, and industrial control applications.

The barrier strip contains 5 contacts with nickel-plated brass for enhanced electrical performance. The polycarbonate housing offers high temperature resistance and self-extinguishing properties. It supports a 400V voltage rating and 25A current capacity, suitable for medium-duty circuits.

Mounting is facilitated by molded mounting holes on each end of the strip. Screw-type top termination with M4 screws ensures secure electrical connections. Wire size compatibility up to 16 AWG supports a broad range of wiring applications.

Operating temperature range from -40°C to 125°C ensures durability in varied environments. Designed for electrical and industrial use including power connectors and terminal block applications. Compact dimensions enable fitting in confined panel and control box spaces.

This RS PRO Barrier Strip is an essential component for organizing and distributing electrical connections safely and efficiently in industrial machinery, electrical panels, power distribution systems, and control gear assemblies. Explore our Electronics & Electricals category for more connectors and terminal blocks suited to your technical requirements.
