KEMET R76_125C Film Capacitor 82 nF 1.6 kV DC 650 V AC ±5 % Tolerance Through Hole R76TN282050H4J

KEMET R76TN282050H4J film capacitor is a high-quality passive component featuring an 82 nF capacitance with ±5 % tolerance, designed for demanding electronic applications requiring 1.6 kV DC and 650 V AC voltage ratings.

This capacitor employs polypropylene film and double metallized polyester film as electrodes, encased within a robust, self-extinguishing plastic housing that offers resistance to solvents and environmental stresses. Its through-hole mounting with 22.5 mm lead spacing and 25 mm lead length facilitates secure soldered connections suitable for printed circuit boards.

Operating across a broad temperature range of -55°C to 125°C, it complies with the automotive AEC-Q200 standard, assuring reliability in rigorous industrial and automotive environments. Its technical features include a very low dissipation factor of 0.1%, low equivalent series resistance (16 mΩ), and precise capacitance tolerance, all contributing to efficient performance in high-frequency, high-voltage circuits.

Typical applications comprise resonant circuits, high-frequency switching and snubber circuits, silicon-controlled rectifier (SCR) and insulated-gate bipolar transistor (IGBT) commutation, and wide-bandgap MOSFETs such as SiC devices. Its reliability and durability ensure consistent function under high ambient temperatures and electrical stress.

Constructed from polypropylene and double metallized polyester film electrodes for durability and performance. Encapsulated in a self-extinguishing and solvent-resistant plastic case for safety. Designed for through-hole mounting with precise lead dimensions for PCB integration.

Meets automotive standard AEC-Q200 for enhanced quality assurance. Wide operating temperature range suitable for harsh environments. Low dissipation factor and ESR for high efficiency in high-frequency applications. Compliance with RoHS and IEC 60286-2 standards ensuring environmental and safety adherence.

Ideal for high-voltage DC and AC applications including industrial and automotive circuits.

This KEMET film capacitor is an essential component in electronic manufacturing, offering superior electrical characteristics and robust design to support demanding industrial, automotive, and commercial applications. For further electronics components and capacitors, browse our comprehensive EnvMart catalogue.
