KEMET R76_125C Film Capacitor 1.8nF ±5% 1kV DC 600V AC Through Hole R76QF118050H0J
Specifications
| Country of Origin | China |
|---|---|
| Capacitance Range | 100 pF - 15 μF |
| Brand | KEMET |
| Height | 9mm |
| Length | 13mm |
| Model | R76QF118050H0J |
| Packaging | Bag |
| Width | 4mm |
| Mount Type | Through Hole |
| Series | R76_125C |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±5 % |
| Capacitance | 1.8nF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Solder |
| Dissipation Factor | 0.1% |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 600V ac |
| Rated DC Voltage | 1kV dc |
| Lead Pitch | 10mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±2.5%, ±5%, ±10% |
| Lead Spacing | 10 mm - 37.5 mm |
| Equivalent Series Resistance ESR | 354mΩ |
Key Features
- Constructed with polypropylene film and double metallized polyester electrodes ensuring stable performance.
- Rated for operation from -55°C up to 125°C, suitable for harsh environments.
- Features a 10mm lead pitch and solder-type terminals with 25mm lead length for reliable connection.
- Designed for high-frequency and high-current applications including snubber and commutation circuits.
- Encapsulated in self-extinguishing, solvent-resistant plastic with thermosetting resin for durability.
- Complies with IEC 60286-2 standards and RoHS directive ensuring quality and environmental compliance.
- Typical uses include resonant circuits, SCR, IGBT, SiC MOSFET circuits within industrial and electronic manufacturing.
Product Description
KEMET R76QF118050H0J Film Capacitor is a high-quality component designed for electronic circuits requiring precise capacitance and voltage ratings. It provides 1.8nF capacitance with a tolerance of ±5%, rated at 1kV DC and 600V AC voltages. The capacitor features through hole mounting with solder terminals and a lead pitch of 10mm, making it compatible with standard PCB assemblies.
This capacitor is constructed from polypropylene film and double metallized polyester electrodes, welded with radial tinned wire leads. It is encapsulated in a self-extinguishing and solvent-resistant plastic case with thermosetting resin for enhanced mechanical and chemical stability. The design supports extended operating temperature range from -55°C to 125°C, suitable for harsh industrial environments.
Compliant with IEC 60286-2 and RoHS standards, the R76_125C series capacitors ensure reliability and environmental friendliness. Automotive standard AEC-Q200 is also met, adding to its quality credentials.
Applications include resonant circuits, high frequency high current snubber circuits, and silicon controlled rectifier (SCR), insulated gate bipolar transistor (IGBT) and SiC (MOSFET) commutation circuits. It is suitable for use in industrial equipment, high-voltage electronics, power supply circuits, and electronic manufacturing processes requiring high reliability and performance.
Stable polypropylene film construction with metallized electrodes. Rated for harsh environments with extensive temperature tolerance. Through hole mount with solder terminals for easy PCB integration. Self-extinguishing, solvent-resistant plastic encapsulation.
Compliant with international standards IEC 60286-2, RoHS, and automotive AEC-Q200. Suitable for resonant, snubber, and commutation circuit applications. Designed for high voltage and current industrial electronic applications.
This product is ideal for industrial, laboratory, electronic manufacturing, and automotive electronics uses. Explore further selections of film capacitors and electronic components at EnvMart for comprehensive solutions.
