ABB Compact Series Push Button Switch Maintained Panel Mount DPST 22 mm Cutout IP69K 250V AC 2A 1SFA619101R1026 CP2-10B-20



Category Push Button Switches & Components Brand ABB Condition New

Specifications

Country of Origin	China
Brand	ABB
Height	30mm
Length	55mm
Model	1SFA619101R1026 CP2-10B-20
IP Rating	IP69K
Width	30mm
Mount Type	Panel
Series	Compact
Maximum Operating Temperature	70°C
Contact Configuration	DPST
Minimum Operating Temperature	-25°C
Panel Cutout Size	22 mm
Terminal type	Screw
Standards/Approvals	IEC 947-5-5EN 60204
Switch Operation	Maintained
Actuator Colour	Black
Contact DC Voltage	250V
Actuator Style	Round
Switch Contact Current	2A
Contact AC Voltage	240V

Key Features

The actuator color is black with a round actuator style.
Panel cutout size is 22 mm supporting compact installation.
Rated for 250 V DC and 240 V AC with a contact current of 2 A.
Features a rugged IP69K rating for dust and water resistance in harsh environments.
Operates effectively from -25°C up to 70°C ensuring reliable performance in varying climates.
Screw terminal design simplifies wiring and connection security.
Designed according to IEC 947-5-5 and EN 60204 standards for safety and performance.
Mechanical durability rated at 0.5 million actuations for long-term use.

Product Description

ABB 1SFA619101R1026 CP2-10B-20 Compact Series Push Button Switch is a maintained push button designed for panel mounting with a 22 mm cutout diameter. The switch features a Double Pole Single Throw (DPST) contact configuration and a robust black plastic actuator that is round in style. It conforms to IEC 947-5-5 and EN 60204 standards ensuring compliance with industrial safety requirements. The device supports 250 V DC and 240 V AC operations with a maximum contact current rating of 2 A, making it suitable for reliable control performance.

The IP69K rating guarantees exceptional protection against dust ingress and high-pressure water jets, enabling the switch to function seamlessly in demanding industrial and automation environments. Operating temperature ranges from -25°C to +70°C allow stable performance across harsh climatic conditions. Screw terminals provide a convenient and secure connection mechanism for various wiring setups.

This maintained switch remains engaged until manually reset, offering sustained control functionality ideal for continuous operation in machinery and control panels. It is used widely in industrial control panels, automation systems, and environments requiring high protection against contaminants.

The actuator color is black with a round style. Panel cutout size is 22 mm supporting compact installation. Rated for 250 V DC and 240 V AC with a contact current of 2 A. Features a rugged IP69K rating for dust and water resistance.

Effective temperature range from -25°C to 70°C ensures reliability. Screw terminal design simplifies wiring and connection security. Conforms to IEC 947-5-5 and EN 60204 standards for safety. Mechanical durability rated at 0.5 million actuations for longevity.

Manufactured in China with durable plastic construction.

Suitable for industrial automation, control panels, and applications where environmental protection and operational reliability are crucial. This compact push button optimizes installation efficiency and enhances operational control with its maintained function and robust construction.

Explore more in the Electronics & Electricals category at EnvMart for advanced switch components and automation solutions.

Explore more products in our Push Button Switches & Components category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model features a Double Pole Single Throw (DPST) contact configuration, allowing for versatile control applications.

It is rated for 250 V DC and 240 V AC, making it suitable for various electrical applications.

The maximum contact current rating for this unit is 2 A, ensuring it can handle moderate electrical loads.

This model has an IP69K rating, providing exceptional protection against dust and high-pressure water jets.

The panel cutout size required for installation is 22 mm, supporting compact mounting.

It operates effectively within a temperature range of -25°C to +70°C, ensuring reliable performance in various environments.

This unit features screw terminals, which simplify wiring and enhance connection security.

It is designed according to IEC 947-5-5 and EN 60204 standards, ensuring compliance with industrial safety requirements.

The actuator is round in style and black in color, providing a clear visual indication of the switch's status.

It is rated for mechanical durability of 0.5 million actuations, indicating its long-term usability in various applications.

This switch is suitable for industrial control panels and automation systems, especially in environments requiring high protection against contaminants.

The country of origin for this model is China, where it is manufactured to meet specified standards.
