KEMET A72 Film Capacitor 1 nF ±10% 2000 V DC 500 V AC Through Hole A72UK1100AA00K

KEMET A72UK1100AA00K Film Capacitor is a precision through hole passive component designed for electronic circuits requiring high voltage and stability. This capacitor features 1 nF capacitance with tight ±10% tolerance, suitable for applications rated up to 2000 V DC and 500 V AC.

The A72 series capacitors are constructed from polypropylene film combined with metal foil or metallized film and metal foil with axial leads of tinned wire. The leads are electrically welded to the metal layer on each end of the capacitor winding ensuring solid electrical continuity. The entire assembly is protected within a durable polyester tape wrapping case sealed with thermosetting resin, providing mechanical stability and environmental protection.

Its axial lead configuration with a lead length of 40 mm and lead diameter of 0.8 mm makes it compatible with through hole PCB mounting. The capacitor dimensions include length of 20.5 mm and width of 8.5 mm, accommodating precise footprint requirements.

This capacitor is designed for operation under a wide temperature range from -55°C to 105°C, making it suitable for demanding industrial, automotive, and high-frequency electronic applications. The device meets IEC 60384-13 and UL standards, ensuring reliability and safety compliance.

Polypropylene film dielectric provides self-healing properties and low dissipation factor (0.1%). Rated for 2000 V DC and 500 V AC operating voltages for high voltage electronic circuits. Axial lead through hole mount type facilitates easy installation in conventional PCB layouts.

Robust plastic case construction ensures protection from mechanical and environmental stress. Capacitance tolerance of ±10% allows stable circuit performance under varying conditions. Ideal for high frequency, power supply filtering and coupling applications in industrial electronics.

Manufactured in Italy with strict quality control.

This KEMET film capacitor is well suited for electronic component assemblies in manufacturing, automation, HVAC systems, industrial controls, and power electronics. It offers high voltage endurance and precise capacitance stability necessary for demanding engineering applications.
