Schurter Non-Resettable Fuse 750mA, 125 V AC/DC, Thermoplastic Body, Time Delay, Reel Package 3404.0113.22
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 125, 125V ac |
| Brand | Schurter |
| Body Material | Thermoplastic |
| Height | 2.6mm |
| Depth | 7.4mm |
| Width | 3.1mm |
| Current Rating | 750mA |
| Series | OMT 125 |
| Maximum Operating Temperature | -40°C |
| Package Type | Reel |
| Minimum Operating Temperature | 85°C |
| Breaking Capacity | 100A |
| Terminal Material | Tin Plated Copper |
| Standards/Approvals | CE, UL 248-14, RoHS, REACH, CSA |
| Fuse Characteristics | Time Delay |
Key Features
- Time delay fuse type ensures protection against transient current spikes.
- Thermoplastic body material provides durability and safety.
- Compact dimensions with 3.1mm width, 2.6mm height, and 7.4mm depth.
- Suitable for use in alarm systems, audio/visual equipment, computer boards, and power supplies.
- Breaking capacity rated at 100A for reliable circuit protection.
- Packaged in a reel format for efficient automated assembly.
- Tin plated copper terminals enhance connectivity and solderability.
- Meets international standards including CE, UL 248-14, RoHS, REACH, and CSA.
Product Description
Schurter 3404.0113.22 Non-Resettable Fuse is a miniature time-delay fuse designed for low voltage surface mount applications with a current rating of 750mA and voltage ratings of 125 V AC and DC. It features a robust thermoplastic body ensuring longevity and safety in electrical circuits.
This fuse is designed to protect sensitive electronic devices such as alarm systems, audio and visual equipment, computer boards, portable telephones, power supplies, and medical instruments by preventing damage from overcurrent conditions.
The compact dimensions of 3.1 mm width, 2.6 mm height, and 7.4 mm depth allow high-density assembly in modern printed circuit boards. It comes supplied on reels to facilitate automated insertion in manufacturing processes, thus improving production efficiency.
The fuse terminals are made from tin plated copper providing excellent solderability and conductivity. It offers a breaking capacity of 100 amperes, suitable for reliable interruption of fault currents in the protected circuit.
Operating across a wide temperature range from -40°C minimum up to 85°C maximum, the fuse complies with key regulatory standards including CE, UL 248-14, RoHS, REACH, and CSA, ensuring performance, safety, and environmental compliance.
Time delay fuse ensures effective circuit protection against transient overloads. Thermoplastic body enhances mechanical robustness and safety. Compact footprint supports space-saving circuit design. High breaking capacity of 100 amperes guarantees fault handling.
Reel packaging supports automated assembly processes. Tin plated copper terminals for reliable electrical connection. Certified to international electrical and environmental standards. Wide operating temperature range suitable for diverse applications.
This Schurter fuse is ideal for industrial, commercial, and medical electronics applications requiring dependable overcurrent protection within compact form factors. EnvMart offers this product to support high-quality circuit protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this fuse is 750mA.
It supports voltage ratings of 125 V AC and DC.
The breaking capacity is rated at 100A, allowing it to reliably interrupt fault currents.
The fuse has compact dimensions of 3.1 mm width, 2.6 mm height, and 7.4 mm depth.
The body of the fuse is made from thermoplastic material, enhancing its durability and safety.
This model is a time delay fuse, designed to protect against transient current spikes.
The fuse operates within a temperature range from -40°C to 85°C.
It features tin plated copper terminals, which enhance solderability and conductivity.
The fuse is supplied in a reel package, facilitating automated assembly processes.
It complies with several international standards including CE, UL 248-14, RoHS, REACH, and CSA.
This fuse is suitable for use in alarm systems, audio/visual equipment, computer boards, and power supplies.
