Bartec Momentary Push Button Control Station Thermoplastic Black Enclosure, 1 Cutout, Red Button, IP67 07-3513-10LRRLYYLGG

Bartec 07-3513-10LRRLYYLGG momentary push button control station features a thermoplastic black enclosure with a single 22mm cutout accommodating a red plastic push button. This control station is engineered for industrial and automation applications demanding robust, high ingress protection rated devices, offering IP67 and IP66 ratings that ensure reliable performance in harsh environments.

The momentary push button utilizes screw terminals for secure electrical connection and is suitable for a broad temperature operating range from 25°C up to 85°C. The enclosure dimensions, measuring 50mm in length, 30mm in width, and 42.5mm in depth, provide a compact footprint aiding installation in constrained spaces.

The Bartec comEx system supporting this control station offers flexible control and indication options with up to three devices per enclosure, and provisions for plastic or metal cable glands, including two M20 glands. The metal glands are secured with metal earth plate sheets within the enclosure, ensuring enhanced safety and grounding compliance.

This product carries ATEX certification, confirming suitability for potentially explosive atmospheres, making it ideal for hazardous area industrial control systems in manufacturing, electrical panels, process control, and automation sectors.

The control station includes a single cutout designed for a 22mm diameter momentary red push button. The enclosure is constructed from durable thermoplastic and is black in color. Rated at IP67 and IP66, providing dust and water ingress protection.

Screw type terminals ensure reliable electrical connections. Operates safely from minimum 25°C to maximum 85°C ambient temperatures. Certified to ATEX standards for use in hazardous environments. Supports up to two M20 cable glands for cable entry configuration.

Compact size and robust construction support versatile industrial applications.

Bartec's range of control stations, including model 07-3513-10LRRLYYLGG, is designed to meet the stringent demands of industrial automation, electrical panel control, and hazardous area operations. This product provides easy installation, flexible wiring options, and reliable performance to enhance system control safety and efficiency.
