XP Power QHL75 DC/DC Converter 12V DC 6.25A 450V DC Input 180V Input 3W Through Hole 105°C Max Temp -40°C Min QHL75
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power QHL75 DC/DC Converter, 12V dc/ 6 |
| Brand | XP Power |
| Efficiency | 88% |
| Length | 57.9mm |
| Model | QHL75 |
| Depth | 12.7mm |
| Gross Weight | 65g |
| Width | 36.8mm |
| Mount Type | Through Hole |
| Series | QHL75 |
| Maximum Operating Temperature | 105°C |
| Package Type | Quarter Brick |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 450V dc |
| Minimum Input Voltage | 180V |
| Number of Pins | 8 |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 6.25A |
| Isolation Voltage | 3kV |
Key Features
- Operates with a wide input voltage range from 180V to 450V DC.
- Delivers regulated single output voltage of 12V DC with 6.25A output current.
- Offers maximum output power of 3W with 88% efficiency.
- Features 3kV reinforced isolation and ripple noise of 150mV peak-to-peak.
- Designed for through hole mounting with 8 pins in a quarter brick package.
- Supports an industrial operating temperature range from -40°C to 105°C maximum.
- Incorporates protection against short circuit, overvoltage, and overtemperature conditions.
- Constructed with reinforced insulation and baseplate cooled for flexible system designs.
Product Description
The XP Power QHL75 DC/DC Converter model QHL75 is a highly reliable compact power module designed for distributed power architectures requiring a stable 12V DC output at 6.25A current. This converter accommodates a wide DC input voltage range from 180V to 450V, making it suitable for use with AC front ends, PFC front ends, and battery systems.
Its quarter brick package and through hole mounting facilitate flexible integration into various systems. The integral baseplate cooling mechanism ensures effective thermal management up to a maximum operating temperature of 105°C and minimum temperature of -40°C.
The unit offers 3W maximum output power with an efficiency of 88%, along with ripple and noise maintained at 150mV peak-to-peak, ensuring precise voltage regulation for sensitive electronics. It is equipped with 3kV reinforced isolation to enhance safety and performance in demanding environments.
Robust protection features include safeguards for short circuit, overvoltage, and overtemperature conditions, enhancing device longevity and system reliability. With dimensions of 57.9mm in length, 36.8mm in width, and 12.7mm in depth, and an 8-pin footprint, it is engineered for industrial applications requiring dependable power supply solutions.
This product is manufactured in Taiwan, Province Of China, and is ideal for use in industrial automation, laboratory instruments, manufacturing equipment, and commercial power systems. Its regulated single outputs with an adjustable voltage trim of ±20% provide versatility for various load requirements.
Operates with a wide input voltage range from 180V to 450V DC. Delivers regulated single output voltage of 12V DC with 6.25A output current. Maximum output power of 3W with efficiency up to 88%. 3kV reinforced isolation voltage for enhanced safety.
Through hole package with 8 pins in quarter brick footprint. Ripple and noise rated at 150mV peak-to-peak. Industrial operating temperature range of -40°C to 105°C maximum. Includes protection against short circuit, overvoltage, and overtemperature.
Compact dimensions suitable for integration: 57.9mm x 36.8mm x 12.7mm. Suitable for use in industrial, laboratory, commercial, and manufacturing power applications. Browse more DC/DC Converters at EnvMart to find the ideal power solution for your electronics and industrial power supply requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The QHL75 operates with a wide input voltage range from 180V to 450V DC.
It delivers a regulated single output voltage of 12V DC with an output current of 6.25A.
The maximum output power is 3W with an efficiency of 88%.
This model has dimensions of 57.9mm in length, 36.8mm in width, and 12.7mm in depth.
It is designed for through hole mounting with an 8-pin footprint.
The ripple and noise are rated at 150mV peak-to-peak.
It supports an industrial operating temperature range from -40°C to 105°C.
The unit offers 3kV reinforced isolation for enhanced safety.
It incorporates protection against short circuit, overvoltage, and overtemperature conditions.
This product is manufactured in Taiwan, Province Of China.
The QHL75 has one output.
It is suitable for use in industrial automation, laboratory instruments, manufacturing equipment, and commercial power systems.
