Cosel Switching Power Supply 12V DC 300W Universal Input 90-264V AC PCB Mount, 4.6A Output GHA300F-12-R3

Free Delivery in India | Lowest Global Shipping Charges

Cosel Switching Power Supply 12V DC 300W Universal Input 90-264V AC PCB Mount, 4.6A Output GHA300F-12-R3

Name: Cosel Switching Power Supply 12V DC 300W Universal Input 90-264V AC PCB Mount, 4.6A Output GHA300F-12-R3
Brand: Cosel
SKU: 318133
Price: 20.22 USD
Availability: InStock



Category Switching Power Supplies Brand Cosel Condition New

Specifications

Country of Origin	Japan
Brand	Cosel
Power	300W
Efficiency	91%
Length	127mm
Model	GHA300F-12-R3
Depth	35mm
Gross Weight	400g
Width	76.2mm
Mount Type	PCB
Series	GHA300F
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-20°C
Number of outputs	1
Maximum Input Voltage	264V ac
Standards/Approvals	UL, RoHS, cURus, CE
Maximum Output Voltage	12V dc
SMPS Output Current	4.6A
Minimum Input Voltage	90V ac

Key Features

One output channel with a maximum current of 4.6A.
Universal input voltage range from 90V to 264V AC.
High efficiency of 91% ensuring energy saving operation.
Compact PCB mount design measuring 127mm length, 76.2mm width, and 35mm depth.
Operating temperature range from -20°C to 70°C for reliable performance.
Complies with UL, RoHS, cURus, and CE standards for safety and quality.
Open frame construction with built-in protections against overcurrent, overvoltage, and inrush current.
Suitable for 1U rack applications with industrial and medical safety approvals.

Product Description

Cosel GHA300F-12-R3 switching power supply provides a reliable 300W power output at 12V DC, designed for PCB mounting in diverse industrial and medical environments. It features a universal AC input voltage range between 90V and 264V, enabling compatibility in multiple regions.

The unit offers one output delivering 4.6A current, with a remarkable efficiency rating of 91%, reducing energy consumption and heat generation. Compactly sized at 127mm long, 76.2mm wide, and 35mm deep, it fits well into space-constrained applications such as 1U racks.

Operating safely over a wide temperature range from -20°C to 70°C, it is suitable for demanding environments. The power supply carries multiple safety and quality certifications including UL, RoHS, cURus, and CE, ensuring compliance with industry standards.

This open frame power supply also incorporates built-in protection circuits for overcurrent, overvoltage, and inrush current, enhancing durability and operational safety. The harmonic attenuator complies with IEC61000-3-2 Class A for reduced electromagnetic interference.

Ideal for industrial manufacturing, laboratory equipment, medical devices, and HVAC systems, it guarantees stable and efficient power delivery. The product is made in Japan, highlighting its quality craftsmanship and reliability.

One output channel with a maximum current of 4.6A. Universal input voltage range from 90V to 264V AC. High efficiency of 91% ensuring energy saving operation. Compact PCB mount design measuring 127mm length, 76.2mm width, and 35mm depth.

Operating temperature range from -20°C to 70°C for reliable performance. Complies with UL, RoHS, cURus, and CE standards for safety and quality. Open frame construction with built-in protections against overcurrent, overvoltage, and inrush current.

Suitable for 1U rack applications with industrial and medical safety approvals. Manufactured in Japan ensuring high build quality and reliability. Browse a wide selection of Switching Power Supplies and other power solutions at EnvMart for industrial and commercial applications.
