Portescap Brushed DC Motor 3.6 W 24V DC 8.1 mNm Torque 6340 RPM 2 mm Shaft Diameter 22V28-208E.202

Free Delivery in India | Lowest Global Shipping Charges

Portescap Brushed DC Motor 3.6 W 24V DC 8.1 mNm Torque 6340 RPM 2 mm Shaft Diameter 22V28-208E.202

Name: Portescap Brushed DC Motor 3.6 W 24V DC 8.1 mNm Torque 6340 RPM 2 mm Shaft Diameter 22V28-208E.202
Brand: Portescap
SKU: 317047
Price: 163.64 USD
Availability: InStock



Category DC Motors Brand Portescap Condition New

Specifications

Country of Origin	India
Brand	Portescap
Material	Steel Tube
Length	51.1mm
Model	22V28-208E.202
Depth	22mm
Width	22mm
Mount Type	Screw
Current Rating	230mA
Power Rating	3.6W
Sub Type	Brushed
Output Speed	6340rpm
Shaft Diameter	2mm
Shaft Length	6mm
Supply Voltage	24V dc
Standards/Approvals	89/336/CEE, ISO 9001
Maximum Output Torque	8.1mNm
Core Construction	Ironless

Key Features

The motor features a 2 mm diameter steel tube shaft with 6 mm length.
Compact dimensions of 51.1 mm length, 22 mm width, and 22 mm depth.
Screw mount type ensures secure and stable installation.
Current rating is 230 mA for efficient power consumption.
Ironless core construction provides smooth operation and reduced cogging torque.
Complies with standards 89/336/CEE and ISO 9001 for quality assurance.
Suitable for motion, movement, and positioning applications requiring a permanent magnet brushed motor.
Manufactured in India ensuring reliable domestic quality.

Product Description

Portescap 22V28-208E.202 is a high-quality brushed DC motor designed to deliver 3.6 W power at a supply voltage of 24V DC. This motor offers an output speed of 6340 RPM and a maximum torque of 8.1 mNm, making it suitable for precision motion control applications in various industrial fields such as automation, robotics, and instrumentation.

The motor shaft is a 2 mm diameter steel tube with a length of 6 mm, allowing easy integration with different mechanical linkages. With compact outer dimensions of 51.1 mm length, 22 mm width, and 22 mm depth, this motor fits well in space-constrained designs that demand efficient performance.

The screw mount type enhances the stability of the motor installation, minimizing vibrations during operation. The motor operates at a current rating of 230 mA, ensuring energy-efficient functionality. Its ironless core construction minimizes cogging torque and noise, thereby improving smoothness and precision during startup and running.

This brushed DC motor meets the quality and safety standards of 89/336/CEE and ISO 9001, making it reliable for demanding industrial environments. It belongs to a series of DC brushed motors available in voltage ranges from 9 to 35 V DC, all permanent magnet types suitable for motion, movement, or positioning tasks where the user can select suitable drive or gearbox units.

Manufactured in India, the 22V28-208E.202 motor is engineered to provide durable and consistent performance. This product is ideal for applications in electrical automation, control gear, and any industrial automation requiring compact, efficient DC motors.

The motor provides 3.6 W power output at 24V DC supply voltage. Maximum output torque is 8.1 mNm for effective motion control. Shaft diameter is 2 mm with a 6 mm shaft length constructed from steel tube. Compact body dimensions: 51.1 mm length, 22 mm width, and 22 mm depth.

Screw mount provides firm installation capability. Ironless core construction minimizes cogging for smooth operation. Certified to standards 89/336/CEE and ISO 9001. Designed for various automation and control applications requiring precision motors.
