Maxon 22mm Miniature DC Motor 18V DC, 5W, 6.25mNm Torque, 9970rpm, 2mm Shaft Diameter 110124
Specifications
| Country of Origin | Switzerland |
|---|---|
| Brand | Maxon |
| Material | Steel |
| Length | 31.9mm |
| Model | 110124 |
| Depth | 22mm |
| Width | 22mm |
| Mount Type | Screw |
| Current Rating | 374mA |
| Series | Max 22 |
| Power Rating | 5W |
| Output Speed | 9970rpm |
| Shaft Diameter | 2mm |
| Shaft Length | 4.9mm |
| Supply Voltage | 18V dc |
| Gear ratio | 1:1 |
| Standards/Approvals | RoHS |
| Maximum Output Torque | 6.25mNm |
| Core Construction | Ironless |
| Gear Ratio 1 | 1 |
| Maxon DC Motor, 5 W, 36V dc, 6.15 mNm, 9800rpm, 2 mm Shaft DiameterBrand | Maxon |
Key Features
- Operates at 18V DC supply voltage for controlled power output.
- Compact 22mm diameter with 31.9mm length, ideal for tight spaces.
- Steel shaft with 2mm diameter and 4.9mm shaft length ensures mechanical durability.
- Ironless core construction reduces inertia for fast acceleration and high speed stability.
- Low current consumption of 374mA suitable for battery-powered and portable applications.
- Equipped with precious metal brush commutation system for consistent contact resistance.
- RoHS compliant, ensuring environmental compliance and safety.
- Designed for easy mounting with screw type and compatible with 24mm spur or 22mm planetary gearheads.
Product Description
Maxon 110124 is a high-performance 22mm miniature DC motor rated at 5W power and 18V DC supply, designed for precision applications in automation, robotics, and control systems. Operating at a speed of 9970rpm and offering a maximum output torque of 6.25mNm, this motor features an ironless core construction that provides low mechanical inertia, enabling fast acceleration and stable high-speed performance. Its compact dimensions of 22mm width and depth with a length of 31.9mm make it suitable for applications requiring space efficiency.
The motor shaft is crafted from steel with a diameter of 2mm and a length of 4.9mm, offering robust mechanical strength. It incorporates a precious metal brush commutation system to ensure consistent low contact resistance and reduce electrical noise, enhancing operational life. The motor is RoHS compliant, reflecting its adherence to environmental and safety standards.
This Maxon motor is optimized for use with planetary gearheads, enabling quick and tool-free assembly with 24mm spur or 22mm planetary gearheads. Its supply current rating of 374mA allows for high efficiency, particularly in battery-powered servo applications requiring accurate speed and torque control.
Compact 22mm diameter design suitable for tight installation spaces. Ironless core reduces mechanical inertia for responsive acceleration. Precious metal brush system minimizes wear and electrical noise. Mount type screw facilitates easy installation.
Compatible with 24mm spur or 22mm planetary gearheads. Designed for servo systems and automation requiring reliable speed control. RoHS compliant to meet environmental regulations.
Widely applied in industrial automation, robotics, laboratory instruments, and other precision control uses where dependable miniature motors are essential. Enhance your projects with Maxon quality and efficient performance.
Explore more high-quality motors and control gear in EnvMart's extensive catalog.
Explore more products in our DC Motors category.
