Schurter Non-Resettable Fuse Ceramic Body 6.3A Current Rating 277 V AC, 125 V DC 3403.0282.23

Name: Schurter Non-Resettable Fuse Ceramic Body 6.3A Current Rating 277 V AC, 125 V DC 3403.0282.23
Brand: Schurter
SKU: 316214
Price: 2.06 USD
Availability: InStock



Category Non-Resettable Fuse Brand Schurter Condition New

Specifications

Country of Origin	Switzerland
Voltage	277, 125V ac
Brand	Schurter
Body Material	Ceramic
Height	5.35mm
Depth	15.4mm
Width	5.35mm
Current Rating	6.3A
Series	UMT-H
Maximum Operating Temperature	125°C
Package Type	Reel
Minimum Operating Temperature	-55°C
Breaking Capacity	1500A
Terminal Material	Tin Plated Copper
Standards/Approvals	RoHS, REACH, CSA, CE, UL 248-14
Fuse Characteristics	Time Delay
Schurter SMD Non Resettable Fuse 160mA, 277 V ac, 250V dcBrand	Schurter

Key Features

Rated for 6.3 amps current and dual voltage 277 V AC, 125 V DC operation.
Compact dimensions of 5.35 mm width, 5.35 mm height, and 15.4 mm depth.
High breaking capacity of 1500 amps for enhanced circuit safety.
Designed to operate within -55°C minimum and 125°C maximum temperature range.
Features tin plated copper terminals for excellent conductivity and corrosion resistance.
Packaged on reels, suitable for automated surface mount technology assembly.
Compliant with multiple certifications including RoHS, REACH, CSA, CE, and UL 248-14 standards.
Ideal for protection of industrial electronics, sensors, power supplies, and lighting systems.

Product Description

Schurter 3403.0282.23 Non-Resettable Fuse is a high-quality surface mount fuse with a ceramic body designed to provide primary protection for sensitive electronic circuits. Rated at 6.3 amps, it supports dual voltage applications of 277 V AC and 125 V DC, making it versatile for various industrial, automation, and electronic scenarios.

This fuse incorporates time delay characteristics allowing it to withstand temporary current surges without nuisance trips, ensuring reliable operation over a wide temperature range from -55°C to 125°C. The compact size with dimensions of 5.35 mm width, 5.35 mm height, and 15.4 mm depth facilitates efficient space utilization on PCBs and electronics assemblies.

The high breaking capacity of 1500 amps ensures effective protection against short circuits and fault conditions, reducing potential damage to expensive components. Its terminals are made of tin plated copper to enhance electrical conductivity and resist corrosion, contributing to long-term operational reliability.

Offered in reel packaging, this fuse is optimized for convenient surface mount technology placement and soldering, suitable for automated production lines. It complies with international standards and approvals such as RoHS, REACH, CSA, CE, and UL 248-14, confirming its adherence to strict quality and safety requirements.

This product is well suited for use in industrial electronic devices, sensors, power supply units, explosion protected equipment, and diverse lighting applications. Manufactured in Switzerland, it reflects high manufacturing standards for consistent performance and durability.

Rated for 6.3 amperes current with dual voltage capability. Ceramic body material enhances heat resistance and durability. Time delay fuse characteristic for better surge tolerance. High breaking capacity of 1500 amps for circuit safety.

Compact dimensions allow dense PCB layouts. Tin plated copper terminals ensure reliable electrical connection. Compliant with RoHS, REACH, CSA, CE, and UL standards. Ideal for industrial, automation, and electronic applications.

Packaged on reels for automated SMT assembly. Explore more Schurter fuses and components in the Electronics & Electricals category at EnvMart for quality and reliability in your projects.
