Crydom Solid State Relay, 10 A Load, Panel Mount, 72 V dc Load, 32V dc Control DC100D10C

Crydom DC100D10C Solid State Relay is a high-quality panel mount relay designed to handle a 10 amp load current and a maximum load voltage of 72 V dc. It features a 32 V dc control voltage, making it suitable for a wide range of industrial and electrical automation applications.

This relay incorporates an optically isolated MOSFET output which ensures noise immunity and fast, instantaneous switching. The device supports DC switching and is optimized for easy paralleling for higher current loads if needed.

The relay is equipped with screw terminals, allowing for secure and reliable connections in panel mount installations. It has a low off-state leakage current of 0.15 mA which minimizes energy loss in control circuits.

It operates effectively in harsh environmental conditions, with a temperature operating range from -30°C to +80°C. The compact form factor of 58.2 mm length, 22.6 mm width, and 32.9 mm height facilitates space-saving integration in control panels and electrical assemblies.

Compliant with UL, RoHS, and CE certifications, the product ensures adherence to international quality and safety standards. The relay includes an LED status indicator, providing visual feedback for operational status. An optional IP20 cover enhances protection against dust and accidental contact.

This solid state relay is ideal for use in industrial control, automation, motor control, and power supply switching, offering reliable and durable performance. Its panel mount design and features suit it for applications in manufacturing processes, HVAC systems, and other electrical control infrastructures.

Supports a maximum load current of 10 amperes with DC switching capability. Panel mount type relay equipped with screw terminals for secure connection. Operates within a temperature range of -30°C to 80°C, suitable for various industrial environments.

Features optically isolated MOSFET output with instantaneous switching. Low off-state leakage current of 0.15 mA reduces power loss. Compact dimensions facilitate installation in confined spaces. Complies with UL, RoHS, and CE standards ensuring quality and safety.

Includes LED status indicator for operational feedback. Optional IP20 cover available for additional protection. Browse more Solid State Relays and other industrial electrical components on EnvMart for reliable solutions tailored to your control system needs.
