Lapp H07Z-K Series Blue 2.5 mm² Low Smoke Zero Halogen (LSZH) Cross Linked Insulation Hook Up Wire, 100 m, 450/750 4726022

Free Delivery in India | Lowest Global Shipping Charges

Lapp H07Z-K Series Blue 2.5 mm² Low Smoke Zero Halogen (LSZH) Cross Linked Insulation Hook Up Wire, 100 m, 450/750 4726022

Name: Lapp H07Z-K Series Blue 2.5 mm² Low Smoke Zero Halogen (LSZH) Cross Linked Insulation Hook Up Wire, 100 m, 450/750 4726022
Brand: Lapp
SKU: 313961
Price: 329.07 USD
Availability: InStock



Category Hook Up Wire Brand Lapp Condition New

Specifications

Country of Origin	India
Voltage	450, 750V
Brand	Lapp
CROSS SECTIONAL AREA	2.5mm²
Model	4726022
Cable Length	100m
Series	H07Z-K
Outside diameter	4.3mm
Maximum Operating Temperature	90°C
Conductor Material	Bare Copper
Sub Type	Single Core
Minimum Operating Temperature	-40°C
Jacket Material	Low Smoke Zero Halogen (LSZH) Cross Linked Insulation
Standards/Approvals	EAC, CE, EN 50525-3-41
Jacket Colour	Blue

Key Features

This hook up wire features a 2.5 mm² bare copper conductor for reliable electrical conductivity.
The blue LSZH cross linked insulation provides flame retardant properties and reduced toxic emissions during fire.
The wire has an outside diameter of 4.3 mm ensuring compact and flexible cabling.
It operates safely across a temperature range from -40°C to 90°C, suitable for harsh environments.
Certified to EAC, CE, and EN 50525-3-41 standards ensuring compliance with international safety norms.
This 100 m long cable is ideal for internal wiring in control panels, machinery, and conduit installations.
Its halogen-free materials make it suitable for applications where personnel and equipment protection are critical.

Product Description

Lapp 4726022 is a high-quality Blue 2.5 mm² Hook Up Wire with Low Smoke Zero Halogen (LSZH) Cross Linked Insulation designed to deliver safe and reliable electrical performance. Rated for 450/750 V and a maximum operating temperature of 90°C, this cable is ideal for internal wiring tasks in demanding industrial, commercial, and automation environments.

The wire features a bare copper conductor that ensures excellent electrical conductivity and mechanical flexibility. The LSZH insulation limits smoke emission and reduces halogen gas release under fire conditions, making it a preferred choice in spaces where fire safety is paramount, such as underground railways, ships, power plants, and nuclear installations.

Conforming to international standards including EAC, CE, and EN 50525-3-41, the Lapp H07Z-K series Hook Up Wire also meets IEC 60332-1-2 flame retardant requirements. The wire's 4.3 mm outside diameter supports neat cable routing in conduits or electrical panels while tolerating operating temperatures from -40°C to 90°C.

This 100 m length wire is ideal for a broad range of electrical installation applications including control cabinets, switchgear enclosures, and cable ducts. It is harmonized under the HAR standard, suitable for European machine installations, and can be paired with Lapp cable management accessories like SKINTOP CLICK cable glands for superior installation quality.

2.5 mm² bare copper conductor ensures dependable electrical conduction. Flame retardant LSZH insulation minimizes smoke and toxic halogen emissions. Operating voltage of 450/750 V with a temperature range from -40°C to 90°C.

Complies with EAC, CE, EN 50525-3-41, and IEC flame retardant standards. 100 m cable length suitable for industrial and commercial electrical wiring. Designed for installation in dry rooms, conduits, and behind plaster with high fire safety requirements.

Compatible with Lapp’s cable glands and accessories for efficient cable management. Explore EnvMart's extensive portfolio of Lapp cables and wires for your industrial automation, electrical maintenance, and construction projects.
