ABB Residual Current Circuit Breaker with Overload Protection, 13A Current Rating, 3-Pole, 30mA Trip 2CSR273101R1134



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Brand	ABB
Height	93mm
Model	2CSR273101R1134
Depth	69mm
Width	87mm
Standards	IEC/EN 60947-2
Current Rating	13A
Series	DS200
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	3
Standards/Approvals	IEC/EN 60947-2, REACH, RoHS
Rated AC Voltage	400V ac
Tripping Characteristics	Type C
Reset Actuator Type	Lever
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Operating Characteristic	Instantaneous

Key Features

Designed to provide protection against overloads and short-circuit currents.
Offers earth leakage protection with Type A sensitivity.
Equipped with a screw terminal type for secure connections.
Conforms to IEC/EN 60947-2 standards ensuring reliable performance.
Operates at a rated AC voltage of 400V with a breaking capacity of 10kA.
Includes a lever reset actuator for easy manual operation.
Compact dimensions of 93mm height, 87mm width, and 69mm depth.
Manufactured in Italy with compliance to RoHS and REACH regulations.

Product Description

ABB 2CSR273101R1134 Residual Current Circuit Breaker with Overload Protection is engineered for industrial and residential electrical safety applications. This 3-pole breaker with a 13A current rating offers reliable protection against overload currents, short circuits, and earth leakage currents.

The device provides earth leakage protection of Type A, capable of detecting sinusoidal alternating earth faults and offers additional protection against direct and indirect contacts. It operates at a rated voltage of 400V AC and meets international safety standards IEC/EN 60947-2 and IEC/EN 61009-1.

Featuring a breaking capacity of 10kA and instantaneous tripping characteristics (Type C), this breaker ensures quick disconnection under fault conditions, enhancing safety and protecting electrical installations.

The unit integrates a screw terminal type for secure wiring connections and a lever reset actuator for user-friendly operation. Its compact design measures 93mm in height, 87mm in width, and 69mm in depth, facilitating efficient installation within electrical panels.

Manufactured in Italy, the breaker complies with RoHS and REACH environmental standards, ensuring safe and environmentally responsible use. Designed to provide protection against overloads and short-circuit currents. Offers earth leakage protection with Type A sensitivity.

Equipped with a screw terminal type for secure connections. Conforms to IEC/EN 60947-2 standards ensuring reliable performance. Operates at a rated AC voltage of 400V with a breaking capacity of 10kA. Includes a lever reset actuator for easy manual operation.

Compact dimensions of 93mm height, 87mm width, and 69mm depth. Manufactured in Italy with compliance to RoHS and REACH regulations.

This Residual Current Circuit Breaker is ideal for residential, commercial, and light industrial electrical distribution systems where protection against overload, short circuit, and earth leakage is required. It supports safety and compliance needs in electrical installations, helping to prevent electrical hazards.
