ABB Tmax XT Molded Case Circuit Breaker 3-Pole 80A 85kA Breaking Capacity Fixed Type 690V 1SDA068266R1 XT3S 250 TMG 80A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 80A 85kA Breaking Capacity Fixed Type 690V 1SDA068266R1 XT3S 250 TMG 80A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	150mm
Model	1SDA068266R1 XT3S 250 TMG 80A FF
Depth	70mm
Width	105mm
Mount Type	Fixed
Current Rating	80A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	3
Standards/Approvals	IEC, RoHS, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	80 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated current of 80A supports medium load electrical circuits.
Breaking capacity of 85kA ensures high fault clearing capability.
Suitable for AC voltage up to 690V and DC voltage up to 500V.
Comes with front fixed terminals and lever type reset actuator.
Compact dimensions with 105mm width, 70mm depth, and 150mm height.
Conforms to IEC, RoHS, and CE standards ensuring quality and safety.
Designed for disassembly in line with Better World sustainability initiatives.
Manufactured in Italy, reflecting high production standards.

Product Description

ABB 1SDA068266R1 XT3S 250 TMG 80A FF Molded Case Circuit Breaker 3-Pole provides robust circuit protection with an 80A current rating and 85kA breaking capacity. It is engineered for fixed mounting and features a thermal magnetic tripping mechanism, ideal for applications requiring high reliability and safety.

The breaker supports rated AC voltage of 690V and rated DC voltage up to 500V, suitable for diverse industrial and commercial electrical systems. The device is equipped with front fixed terminals for secure connections and a lever-type reset actuator for easy operation.

Its compact dimensions (105mm width, 70mm depth, and 150mm height) allow space-efficient installation in panel boards and switchboards. Compliance with IEC, RoHS, and CE standards guarantees adherence to international quality and environmental safety regulations.

This circuit breaker is part of the ABB Tmax XT series, renowned for durability and performance. It features a Better World product claim for designed disassembly, supporting sustainable practices in electrical component lifecycle management.

Rated frequency at 50/60 Hz offers compatibility with standard power grids globally. Manufactured in Italy, the product meets rigorous production and quality benchmarks. Rated current: 80A ensuring safe circuit operation under rated load conditions.

Breaking capacity: 85kA to handle high fault currents. Fixed mount type for stable installation. Thermal magnetic tripping mechanism for dual protection against overloads and short circuits. Front fixed terminals allow straightforward wiring.

Lever reset actuator for manual circuit reset. Compact dimensions for panel compatibility. Conforms to IEC, RoHS, CE certifications. Part of ABB Tmax XT series for industrial applications.

This molded case circuit breaker is widely used in electrical distribution systems across construction, manufacturing, industrial machinery, commercial buildings, and HVAC systems. Its high breaking capacity and reliable tripping make it suitable for protection of circuits with elevated fault current potentials.

Explore more reliable electrical protection devices like this ABB Tmax XT MCCB by browsing the Molded Case Circuit Breaker category on EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The circuit breaker has a rated current of 80A, suitable for medium load electrical circuits.

It features a breaking capacity of 85kA, which ensures high fault clearing capability.

This model has compact dimensions of 105mm in width, 70mm in depth, and 150mm in height.

It is designed for fixed mounting, providing stable installation in electrical panels.

It supports a rated AC voltage of 690V and a rated DC voltage of up to 500V.

It employs a thermal magnetic tripping mechanism for protection against overloads and short circuits.

The circuit breaker is equipped with a lever-type reset actuator for manual circuit reset.

It conforms to IEC, RoHS, and CE standards, ensuring quality and safety.

The rated frequency is 50/60 Hz, making it compatible with standard power grids globally.

It is manufactured in Italy, reflecting high production standards.

This model is part of the ABB Tmax XT series, known for its reliability in industrial applications.

It is widely used in electrical distribution systems across construction, manufacturing, industrial machinery, commercial buildings, and HVAC systems.
