ABB Residual Current Circuit Breaker with Overload Protection 32A Current Rating, 2-Pole, 30 2CSR255080R1325 DS201 B32 AC30

ABB 2CSR255080R1325 DS201 B32 AC30 Residual Current Circuit Breaker with Overload Protection is engineered to safeguard end-user single-phase circuits by combining overload protection with residual current detection. It features a current rating of 32A and a 2-pole design for effective circuit interruption in industrial, commercial, and residential electrical distribution systems.

The device employs a thermal magnetic tripping mechanism that ensures rapid response to overloads and short circuits, while Type B tripping characteristics protect against pulsating DC earth fault currents. With a trip sensitivity of 30mA, it provides enhanced safety against electric shock risks by detecting sinusoidal alternating earth fault currents.

Mountable on standard DIN rails, the circuit breaker offers secure connections via screw terminals and has compact dimensions of 85mm height, 69mm depth, and 35mm width, facilitating installation in electrical panels with limited space. It operates at a rated AC voltage of 230V and delivers a breaking capacity of 6kA, ensuring robust fault clearance capabilities.

Additional features include an earth leakage protection type AC and protection ratings of IP40 for the housing and IP20 for terminals, making it suitable for a variety of indoor electrical environments. The breaker complies with IEC and RoHS standards, signifying adherence to global quality and environmental regulations.

This circuit breaker is ideal for use in electrical automation, residential and commercial building installations, and industrial electrical distribution systems where reliable overload and residual current protection is critical.

Designed for single-phase circuit protection against overload and short circuits. Equipped with thermal magnetic tripping mechanism for reliable operation. Type B tripping characteristics ensure protection against pulsating DC residual currents.

Constructed for DIN rail mounting with screw terminals for secure connections. Dimensions of 85mm height, 69mm depth, and 35mm width for compact installation. Rated AC voltage of 230V suitable for residential and commercial applications.

Breaking capacity rated at 6kA to handle high fault currents safely. Earth leakage protection of AC type with 30mA trip sensitivity for personnel safety. Compliance with IEC and RoHS standards for quality and environmental safety.

Housing provides IP40 protection while terminals are protected to IP20 level. Explore a wide range of circuit breakers and electrical protection devices at EnvMart for your industrial and commercial needs.
