ABB Residual Current Circuit Breaker with Overload Protection 6A Current Rating 1-Pole 30 mA 2CSR275180R1064 DS201 M C6 A30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR275180R1064 DS201 M C6 A30
Depth	69mm
Width	85mm
Mount Type	DIN Rail
Current Rating	6A
Series	DS201
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	RoHS
Rated AC Voltage	230V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A

Key Features

Features a single-pole design optimized for DIN rail mounting.
Instantaneous tripping mechanism ensures rapid response to electrical faults.
Has a 10 kA short-circuit breaking capacity for effective surge protection.
Equipped with screw terminals for secure conductor connections.
Thermal magnetic tripping characteristics type C for accurate protection.
Includes a toggle switch reset actuator for easy system restoration.
A blue indicator on the lever visibly shows fault and trip status.
Compact dimensions with a width of 85mm, height of 85mm, and depth of 69mm.

Product Description

ABB 2CSR275180R1064 DS201 M C6 A30 Residual Current Circuit Breaker with Overload Protection is engineered for industrial and commercial electrical safety systems. It safeguards electrical installations by interrupting faulty current flow caused by leakage or overload conditions at a rated current of 6A and trip sensitivity of 30 mA.

This 1-pole device mounts quickly on DIN rails, facilitating streamlined installation in control panels or distribution boards. The thermal magnetic trip mechanism (Type C characteristic) provides selective and accurate fault detection, minimizing nuisance trips while securing connected equipment.

With a breaking capacity of 10kA, it effectively protects against short circuits and surges, enhancing system reliability. The screw terminal design secures wiring and prevents loosening from vibration or handling. An intuitive toggle switch reset mechanism allows swift recovery after fault clearance, reducing downtime.

The breaker’s compact form factor (85mm width, 85mm height, 69mm depth) fits into tight enclosures, ideal for packaging lines, engineering workshops, and plastic processing environments requiring high electrical safety standards.

A colored status indicator displays fault conditions visibly on the toggle lever, enabling quick diagnostics without panel disassembly. Compliance with RoHS ensures adherence to environmental regulations, making it suited for eco-conscious projects.

Reliable protection with thermal magnetic trip and fault detection. Easy installation with DIN rail mounting and screw terminals. Compact, robust design for industrial and commercial use. Visual fault indication for maintenance efficiency.

Long operational life up to 10,000 operations.

This ABB Residual Current Circuit Breaker is a critical component for protecting electrical circuits against overload or earth leakage hazards. Its tailored design fits demanding industrial and laboratory electrical distribution applications. Explore EnvMart's extensive electrical protection device catalog to find compatible accessories and circuit breakers for your safety systems.
