ABB Residual Current Circuit Breaker with Overload Protection 13A 1-Pole 30mA Trip Sensitivity Type B DS-ARC1 M B13 A30

ABB DS-ARC1 M B13 A30 Residual Current Circuit Breaker with Overload Protection is engineered for industrial, commercial, and residential electrical safety applications. It integrates earth fault current detection with overcurrent protection in a single compact device, rated at 13A with a single pole configuration and 30mA trip sensitivity to prevent electric shock hazards.

This breaker features a thermal magnetic tripping mechanism that combines thermal overload and magnetic short-circuit protection, providing reliable interruption during fault conditions. Its DIN rail mounting system allows seamless integration into System Pro M Compact busbar assemblies without additional wiring complexity.

The breaker supports supply connections from both top and bottom, facilitated by double slots for both cables and busbars to enhance wiring flexibility and reduce installation time. Its compact dimensions (85mm x 85mm x 52.5mm) allow for space-efficient panel arrangements.

Designed with Type B tripping characteristics, it is suitable for protecting circuits with DC components and sensitive electronic equipment. The toggle switch actuator enables easy manual resetting post-trip events.

Certified to IEC and RoHS standards, this breaker ensures compliance with international safety and environmental norms. An LED indicator and dual test buttons provide straightforward operation verification and status monitoring.

Typical applications include electrical distribution boards, industrial machinery protection, and residential circuit safety, particularly where combination of earth leakage and overload protection is required.

Manufactured in Italy, the DS-ARC1 series represents ABB’s commitment to quality and reliability in electrical protection devices. Equipped with thermal magnetic tripping mechanism for reliable overload protection. Compact DIN rail mount for easy installation in electrical panels.

Rated for 240V AC voltage with 10kA breaking capacity ensures robust performance. Includes Type A earth leakage protection and Type B tripping characteristics. Features a toggle switch reset actuator for convenient manual control.

Dimensions are 85mm height, 85mm depth, and 52.5mm width for space-efficient setup. Supplies connection possible from both top and bottom with double slots for cables and busbars. Compliance with IEC and RoHS standards guarantees quality and safety.

Manufactured in Italy ensuring high build standards. Explore further high-quality circuit protection devices and electrical components at EnvMart for your industrial, construction, and electrical infrastructure needs.
