ABB Residual Current Circuit Breaker with Overload Protection, 13A Current Rating, 1-Pole, 30 mA Trip DS-ARC1 B13 A30

ABB DS-ARC1 B13 A30 Residual Current Circuit Breaker with Overload Protection integrates a 13A rated current capacity and 30mA trip sensitivity within a compact 1-pole device. Operating at 240V AC, this breaker combines thermal magnetic tripping mechanisms delivering precise overload and short-circuit protection essential for residential, commercial, and industrial electrical installations.

The device is part of the System Pro M Compact range and supports DIN rail mounting that simplifies installation and maintenance. It offers a breaking capacity of 6kA ensuring effective fault current interruption to protect electrical circuits and enhance safety.

Its toggled switch reset actuator enables easy manual operation, while dual slots at top and bottom facilitate versatile wiring with busbars or cables. Compact dimensions (85mm height, 85mm depth, 52.5mm width) allow for efficient space utilization within distribution boxes.

ABB DS-ARC1 incorporates advanced features including LED indicators for straightforward network troubleshooting, two separate test buttons verifying AFDD and RCD functionalities, and continuous internal self-tests to ensure ongoing reliability and protection against arc faults, overvoltages, overcurrents, and earth leakage.

Conforming to RoHS and IEC standards, this device is manufactured in Italy ensuring high manufacturing quality and compliance. It is suitable for use in industrial, commercial, and residential electrical protection applications requiring sensitive earth leakage detection combined with overload protection.

Incorporates thermal magnetic tripping mechanism for reliable overload and short-circuit protection. Designed for 1-pole installation with DIN rail mount type for easy setup. Rated AC voltage of 240V suitable for residential and industrial applications.

Breaking capacity of 6kA ensures robust fault interruption capabilities. Equipped with toggle switch reset actuator for user-friendly operation. Supports double slot supply from top and bottom enhancing wiring flexibility.

Compact dimensions of 85mm height, 85mm depth, and 52.5mm width for space saving installation. Complies with RoHS and IEC standards assuring quality and environmental compliance. LED indicators and self-test features provide easy fault detection and maintenance.
