ABB Residual Current Circuit Breaker with Overload Protection 6A, 1-Pole, 30mA Trip Sensitivity, Type B DS-ARC1 B6 A30

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Circuit Breaker with Overload Protection 6A, 1-Pole, 30mA Trip Sensitivity, Type B DS-ARC1 B6 A30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	DS-ARC1 B6 A30
Depth	85mm
Width	52.5mm
Mount Type	DIN Rail
Current Rating	6A
Series	DS-ARC1
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	1
Standards/Approvals	RoHS, IEC
Rated AC Voltage	240V ac
Tripping Characteristics	Type B
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Supply possible both from top and bottom side	double slots available for connection with cables and busbars

Key Features

Thermal magnetic tripping mechanism ensures precise disconnection during faults.
Includes Type A earth leakage protection ensuring enhanced safety.
Compact DIN rail mounting allows easy installation in electrical panels.
LED indicators and two test buttons facilitate quick troubleshooting and verification.
Breaking capacity of 6kA provides protection against short circuits.
Compatible with System pro M compact® accessories for modular extension.
Supply connections on both top and bottom aid flexible wiring and busbar integration.
Manufactured in Italy under RoHS and IEC standards ensuring quality and compliance.

Product Description

ABB DS-ARC1 B6 A30 Residual Current Circuit Breaker with Overload Protection is a state-of-the-art electrical safety device designed for precise protection of electrical circuits against overcurrents and earth faults. Featuring a 6A current rating and 30mA trip sensitivity, this 1-pole breaker effectively safeguards installations in various industrial and residential environments.

The innovative Series DS-ARC1 is part of the System pro M Compact range, offering a compact three-module width design that houses advanced arc fault detection and residual current functionalities in a single device. It incorporates a thermal magnetic tripping mechanism with Type B characteristics to ensure reliable disconnection during fault conditions.

Its DIN rail mounting configuration facilitates straightforward installation in control panels, complemented by screw-type terminals for secure wiring. The device includes LED indicators and two test buttons to verify the correct functioning of both the Arc Fault Detection Device (AFDD) and the Residual Current Device (RCD), enhancing maintenance efficiency.

The breaker boasts a strong breaking capacity of 6kA and accepts supply connections from both top and bottom using double slots for cables and busbars, thus providing enhanced wiring flexibility. Compliance with RoHS and IEC standards along with manufacturing origin in Italy certify the product's high quality and regulatory conformance.

Rated AC voltage: 240V AC. Current Rating: 6A. Number of Poles: 1. Trip Sensitivity: 30mA. Tripping Characteristics: Type B. Mount Type: DIN Rail. Terminal Type: Screw. Earth Leakage Protection Type: Type A. Breaking Capacity: 6kA.

Reset Actuator Type: Toggle Switch.

This device is ideal for use in residential, commercial, and industrial electrical installations where protection against arc faults and earth leakage currents is essential for safety and equipment protection. It is a suitable choice for automation, building electrical systems, and panel boards.

Explore more high-quality circuit protection devices and compatible accessories in the ABB product range available at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 6A.

The trip sensitivity is 30mA, providing effective protection against earth faults.

It has a breaking capacity of 6kA, which protects against short circuits.

This unit is designed for DIN rail mounting, allowing for easy installation in electrical panels.

The dimensions are 85mm in height, 85mm in depth, and 52.5mm in width.

It provides Type A earth leakage protection, enhancing safety in electrical installations.

It features a thermal magnetic tripping mechanism for reliable disconnection during faults.

Yes, it complies with RoHS and IEC standards, ensuring quality and regulatory conformance.

This unit uses a toggle switch as the reset actuator type.

Yes, it accepts supply connections from both the top and bottom, providing flexible wiring options.

It is part of the System Pro M Compact range, which integrates advanced functionalities in a compact design.

It is suitable for residential, commercial, and industrial electrical installations requiring protection against arc faults and earth leakage currents.
