Siemens Inverter Drive SINAMICS G115D Series 1.5 kW 3-Phase 480V Panel Mount 6SL3520-3XN01-5AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-3XN01-5AF0 |
| IP Rating | IP65, IP66 |
| Mount Type | Panel |
| Series | SINAMICS G115D |
| Overall Width | 380mm |
| Power Rating | 1.5kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 6.2A |
| Standards/Approvals | CE, C-Tick (RCM), EAC, KCC, REACH, SEMI F47 |
| Maximum Supply Voltage | 480V |
| Overall Depth | 129mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
Key Features
- This inverter drive supports efficient control of SIMOGEAR 2KJ8 geared motors.
- Designed for panel mounting with IP65 and IP66 ratings for protection against dust and water.
- Operates reliably across a wide temperature range from -30°C to +55°C.
- Features integrated safety functions including STO with fail-safe digital input or PROFIsafe compatibility.
- Capable of operating at output frequencies up to 550 Hz.
- Compact design with 380 mm width and 129 mm depth allows space-saving installation.
- Complies with multiple standards and approvals such as CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47.
- Optimized for horizontal conveyor system applications requiring encoderless vector control.
Product Description
Siemens 6SL3520-3XN01-5AF0 is a robust and versatile inverter drive from the SINAMICS G115D series, providing 1.5 kW power for demanding industrial automation processes. This 3-phase, 480V frequency converter is designed for seamless integration with SIMOGEAR 2KJ8 geared motors and supports both IE3 asynchronous and IE4 synchronous reluctance efficiency class motors, making it highly efficient for various motor types.
The device features a panel mount design with IP65 and IP66 protection levels ensuring reliable operation in harsh industrial environments, including exposure to dust and water. Engineered to function across a broad ambient temperature range (-30°C to +55°C), it reliably serves diverse climate conditions.
With a maximum output current of 6.2 A and output frequency capability up to 550 Hz, this inverter supports precise and effective speed control, including sophisticated encoderless vector control suited for horizontal conveyor systems.
Integrated safety functions include safe torque off (STO) capability via fail-safe digital inputs or PROFIsafe protocol, enhancing operational safety without additional hardware. The compact form factor with overall dimensions of 380 mm width and 129 mm depth allows easy installation and minimizes cabinet space requirements, lowering cooling demands.
Siemens emphasizes sustainability with this better world product, which adheres to various global standards like CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47, demonstrating compliance and quality assurance.
This inverter drive is ideal for use in industrial automation, manufacturing plants, conveyor systems, and other applications requiring reliable AC motor drives with enhanced energy efficiency and safety.
This inverter drive supports efficient control of SIMOGEAR 2KJ8 geared motors. Designed for panel mounting with IP65 and IP66 ratings for protection against dust and water. Operates reliably across a wide temperature range from -30°C to +55°C.
Features integrated safety functions including STO with fail-safe digital input or PROFIsafe compatibility. Capable of operating at output frequencies up to 550 Hz. Compact design with 380 mm width and 129 mm depth allows space-saving installation.
Complies with multiple standards and approvals such as CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47. Optimized for horizontal conveyor system applications requiring encoderless vector control. Environmentally friendly, energy-saving better world product certified by Siemens.
Explore more Siemens Inverter Drives and automation components on EnvMart for enhanced industrial performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens Inverter Drive SINAMICS G115D has a power rating of 1.5 kW.
This unit has overall dimensions of 380 mm in width and 129 mm in depth.
It is capable of operating at output frequencies up to 550 Hz.
The operating temperature range for this model is from -30°C to +55°C.
This inverter drive is designed for seamless integration with SIMOGEAR 2KJ8 geared motors and supports both IE3 asynchronous and IE4 synchronous reluctance efficiency class motors.
It features integrated safety functions including safe torque off (STO) capability via fail-safe digital inputs or PROFIsafe protocol.
The maximum output current for this inverter drive is 6.2 A.
This model has IP65 and IP66 ratings for protection against dust and water.
It complies with several standards and approvals including CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47.
This inverter drive is designed for panel mounting.
The country of origin for this model is the United Kingdom.
It is optimized for horizontal conveyor system applications requiring encoderless vector control.
