TE Connectivity PCB Power Relay 48V DC Coil 6A Switching Current SPDT V23092A1048A301

TE Connectivity V23092A1048A301 PCB Power Relay is engineered for industrial and electronic applications requiring reliable switching capabilities. This SPDT (Single Pole Double Throw) relay supports a coil voltage of 48V DC and can handle switching currents up to 6A, making it suitable for power control in automation, electrical, and control systems.

Its compact size with dimensions of 28mm length, 15mm height, and 5mm width allows for high density mounting on PCBs, optimizing space without compromising performance. The coil power consumption is low at 217mW, enhancing energy efficiency while maintaining high coil sensitivity of 170mW.

The relay operates effectively in a wide temperature range from -40°C up to +85°C, ensuring durable operation in industrial and harsh environments. It delivers a switching AC voltage rating of 400V AC and a switching power capacity of 1.5kVA. The contact material is silver alloy, chosen for excellent electrical conductivity and resistance to corrosion.

Additional features include robust isolation between coil and contact rated at 4000VAC, providing electrical safety and reducing risk of interference. The terminal type is solder, allowing secure attachment to PCB pads. This product complies with RoHS standards, confirming its adherence to environmental safety guidelines.

This power relay is particularly suited to electrical automation, manufacturing equipment, HVAC control systems, and other applications demanding reliable power relay switching on printed circuit boards.

This power relay features a compact design with 5mm thickness for high density PCB mounting. Coil resistance is 10.6kΩ supporting coil power of 217mW for efficient operation. Operating temperature ranges from -40°C to +85°C ensuring durability in diverse environments.

It provides a switching AC voltage up to 400V AC and switching power of 1.5kVA. Contact material is silver alloy for high conductivity and durability. Isolation voltage between coil and contact is 4000VAC for safety and reliable performance.

Mount type is PCB solder terminal facilitating easy installation on printed circuit boards. The relay belongs to the SNR series, known for slim relays with high coil sensitivity of 170mW. Explore more quality Power Relays from TE Connectivity and related electrical components on EnvMart for your industrial and electronic system needs.
