Honeywell Technologies Piezoresistive Pressure Sensor 1034 kPa Maximum Operating Pressure Board Mount SMT 8 HSCMAND150PA4A3
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 1034 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | HSCMAND150PA4A3 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Width | 13.3mm |
| Mount Type | Board |
| Series | HSC |
| Maximum Operating Temperature | +85°C |
| Port Type | Single Axial Barbed |
| Package Type | SMT |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | ISO 9001 |
| Pin Count | 8 |
| Automotive Standard | ISO 9001 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0psi |
| Maximum Overload Pressure | 1723kPa |
Key Features
- Compact board-mounted piezoresistive pressure sensor for absolute, gage, or differential pressure.
- Operates with single supply voltage from 3.3V to 5V for flexible integration.
- High accuracy of ±0.25% FSS reduces system calibration effort.
- Analogue output updated at approximately 1kHz, digital output at about 2kHz.
- Operational temperature range from -20°C to +85°C suitable for varied environments.
- Low power consumption design ideal for power-sensitive applications.
- Compliant with ISO 9001 standards ensuring consistent quality.
- Designed for PCB mounting with SMT package and 8 pins for reliable connectivity.
Product Description
Honeywell Technologies HSCMAND150PA4A3 is a piezoresistive pressure sensor designed for precise measurement of absolute, gage, or differential pressure in non-corrosive gases and selected non-ionic liquids. This SMT 8-pin board-mounted sensor supports operating pressures up to 1034 kPa with a maximum overload pressure rating of 1723 kPa. Featuring a compact form factor of 13.75mm height, 13.3mm width, and 10mm length, it integrates easily into PCB assemblies.
The sensor offers accurate pressure measurement with ±0.25% full-scale span (FSS) accuracy and compensates for temperature variations from -20°C to +85°C. It operates on single supply voltages ranging from 3.3V to 5V, producing a ratiometric analogue output updated around 1 kHz and a high-resolution digital output at approximately 2 kHz. Its extremely low power consumption makes it suitable for applications requiring energy efficiency.
Manufactured following ISO 9001 standards and automotive grade compliance, the HSCMAND150PA4A3 is ideal for industrial, laboratory, HVAC, and pneumatic control systems requiring compact, reliable pressure sensing solutions. The single axial barbed port supports robust pressure connection.
The device is designed for seamless PCB integration with its SMT package type and 8-pin configuration, ensuring secure mounting and connectivity. Typical applications include hydraulic and pneumatic system monitoring, environmental instrumentation, and process control equipment.
Key Features:. Compact SMT 8-pin piezoresistive pressure sensor for versatile pressure measurement requirements. Operating pressure range up to 1034 kPa with a maximum overload pressure of 1723 kPa. High precision accuracy of ±0.25% FSS minimizes calibration needs.
Wide temperature operating range from -20°C to +85°C for varied environments. Operates from 3.3V to 5V supply facilitating flexible system designs. Fast output update rates: ~1 kHz analogue, ~2 kHz digital for responsive readings.
Low power consumption suitable for battery-operated or low-energy devices. Certified to ISO 9001 standards ensuring product reliability and quality. Explore more in EnvMart's Electronics & Electricals Sensors category for high-quality Pressure Sensor ICs from Honeywell and other trusted manufacturers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this pressure sensor is 1034 kPa.
It has an accuracy of ±0.25% full-scale span (FSS).
The operating temperature range is from -20°C to +85°C.
This sensor provides a ratiometric analogue output updated at approximately 1 kHz and a digital output at about 2 kHz.
It operates with a single supply voltage ranging from 3.3V to 5V.
The dimensions are 13.75mm in height, 13.3mm in width, and 10mm in length.
This model is designed for board mounting with an SMT (Surface Mount Technology) package.
The maximum overload pressure is rated at 1723 kPa.
It features a single axial barbed port for robust pressure connection.
Yes, it is compliant with ISO 9001 standards, ensuring consistent quality.
This sensor is suitable for applications in industrial, laboratory, HVAC, and pneumatic control systems.
The sensor features an 8-pin configuration for reliable connectivity.
