Vishay 100 V 3 A Schottky Barrier Schottky Diode 2-Pin DO-221AD Surface Mount VSS8D3M10HM3/H

Name: Vishay 100 V 3 A Schottky Barrier Schottky Diode 2-Pin DO-221AD Surface Mount VSS8D3M10HM3/H
Brand: Vishay
SKU: 289867
Price: 0.24 USD
Availability: InStock



Category Schottky Diode Brand Vishay Condition New

Specifications

Country of Origin	China
Brand	Vishay
Height	2.7mm
Length	5mm
Model	VSS8D3M10HM3/H
Mount Type	Surface
Series	VSS8D3M10
Maximum Operating Temperature	175°C
Package Type	DO-221AD
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	3A
Peak Reverse Repetitive Voltage Vrrm	100V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Non-Repetitive Forward Surge Current Ifsm	60A
Maximum Forward Voltage Vf	0.58V

Key Features

This diode features a maximum continuous forward current of 3 Amperes.
It offers a peak reverse repetitive voltage of 100 Volts ensuring reliability in various circuits.
The maximum forward voltage drop is 0.58 V, reducing power losses efficiently.
Operation temperature ranges from -40°C to 175°C, suitable for harsh environments.
The diode has a single diode configuration with low leakage current.
It is compliant with RoHS standards and meets automotive standard AEC-Q101.
Compact dimensions with a length of 5mm and height of 2.7mm allow easy PCB mounting.
Peak non-repetitive forward surge current of 60 Amperes supports high transient loads.

Product Description

Vishay VSS8D3M10HM3/H Schottky Diode is a high-performance 2-pin diode with a surface mount DO-221AD package. Rated for 100 V peak reverse voltage and 3 A continuous forward current, this diode is ideal for fast switching, low forward voltage drop, and low power loss applications.

Designed for industrial, commercial, and automotive electronic circuits, it excels in high frequency inverters, freewheeling diodes, DC/DC converters, and polarity protection. The diode supports a wide operating temperature range from -40°C to 175°C, making it reliable in demanding environments.

Its compact size with length 5 mm and height 2.7 mm enables automated PCB assembly and space savings. With a low forward voltage of 0.58 V and peak surge current rating of 60 A, the device minimizes energy loss while handling transient loads efficiently.

The device is RoHS compliant and certified to automotive standard AEC-Q101, ensuring quality and environmental safety. It is manufactured in China and carefully designed to meet high standards for semiconductor diodes.

This Schottky diode offers a low forward voltage drop for improved efficiency. Its 2-pin DO-221AD package supports surface mount technology for modern assembly. High surge current capacity allows handling transient power spikes safely.

Suitable for multiple applications including industrial and automotive electronic circuits. Meets RoHS and AEC-Q101 automotive certification standards for quality assurance. Compact size and surface mount design enable automated placement and minimized PCB footprint.

Wide operating temperature range ensures reliability across various operating conditions. Explore this and other semiconductor components in the Schottky Diodes & Rectifiers category at EnvMart for quality and reliability in your electronic designs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum continuous forward current for this model is 3 Amperes.

This diode has a peak reverse repetitive voltage rating of 100 Volts.

The maximum forward voltage drop is 0.58 Volts, which helps reduce power losses.

It operates within a temperature range of -40°C to 175°C, making it suitable for harsh environments.

The diode comes in a DO-221AD package type, designed for surface mount applications.

The peak non-repetitive forward surge current rating is 60 Amperes, allowing it to handle high transient loads.

This diode features a 2-pin configuration.

Yes, it is RoHS compliant and meets the automotive standard AEC-Q101.

The country of origin for this diode is China.

This model is a Schottky type rectifier, known for its fast switching capabilities.

The diode has a length of 5mm and a height of 2.7mm, making it compact for PCB mounting.

It is suitable for applications in industrial, commercial, and automotive electronic circuits, including high frequency inverters and DC/DC converters.
