Vishay 12.03 V General Purpose Zener Diode 500 mW Surface Mount 2-Pin DO-219AC PLZ12B-HG3_A/H

Vishay PLZ12B-HG3_A/H brand 12.03 V general purpose Zener diode delivers reliable 500 mW power dissipation in a compact DO-219AC (MicroSMF) surface mount package, ideal for electronic circuits requiring voltage regulation.

This surface mount diode features a single element chip configuration with excellent stability and low leakage current. Its ultra-small low-profile MicroSMF package (2-pin, 2.5 mm length, 0.6 mm height) supports wave and reflow soldering processes withstanding soldering temperatures up to 260 °C for 10 seconds at the terminals.

The device operates over a wide temperature range from -55 °C to 150 °C, making it suitable for harsh industrial environments as well as automotive electronics complying with AEC-Q101 standards.

Technical attributes such as a maximum Zener impedance of 12 Ω, test current of 10 mA, and a maximum reverse leakage current of 200 nA ensure efficient voltage clamping and circuit protection.

Low leakage current enhances device reliability. Compact surface mount package saves PCB space. High temperature soldering resistance for robust assembly. Wide operating temperature for industrial and automotive use. Compliance with IEC 61000-4-2, IEC 61760-1 standards and RoHS ensures quality and environmental safety.

This Zener diode is ideal for use in voltage regulation and protection applications in industrial machinery, automotive electronic systems, power supplies, and discrete semiconductor circuits.

Explore Vishay's range of Zener Diodes and other semiconductor products at EnvMart for quality and reliability.
