STMicroelectronics Electronic Fuse 18V, 60A Output Current, Surface Mount QFN Package STEF12H60MPUR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 950μm |
| Length | 5mm |
| Model | STEF12H60MPUR |
| Mount Type | Surface |
| Series | STEF12H60M |
| Output Current | 60A |
| Maximum Operating Temperature | 125°C |
| Package Type | QFN |
| Minimum Operating Temperature | -40°C |
| Maximum Input Voltage | 18V |
| Current Limit | 60mA |
| Minimum Input Voltage | 5V |
| Pin Count | 32 |
Key Features
- Optimized for monitoring output current and input voltage on 12 V DC power lines.
- Features programmable turn-on time for precise control.
- Provides accurate current monitor and temperature monitor signals.
- Includes overcurrent and fault status flags for reliable protection.
- Equipped with internal MOSFET self-diagnostic and supports parallel operation.
- Compact QFN package with surface mount design and 32 pins.
- Operating temperature ranges from -40°C to 125°C for wide environment suitability.
Product Description
The STMicroelectronics STEF12H60MPUR electronic fuse is engineered for applications utilizing 12 V DC rails, capable of handling output currents up to 60A and input voltages up to 18V. This surface-mounted device incorporates a QFN package with a compact footprint of 5 mm length and a height of 950 μm, featuring 32 pins for reliable connectivity.
It is optimized to monitor both the output current and input voltage, providing accurate current and temperature signals. The fuse integrates programmable turn-on time and advanced safety features including overcurrent and fault status flags, enhancing its reliability in power management systems.
The internal MOSFET self-diagnostic functionality ensures device health monitoring, while parallel operation capability allows for scalability in higher current applications. The device operates effectively across a wide temperature range from -40°C to 125°C, making it suitable for diverse industrial, automotive, and electronic power management environments.
This electronic fuse is ideal for electronics manufacturing, power supply protection, automotive electronics, and industrial equipment requiring precise current and voltage monitoring with secure, reliable fuse protection.
Optimized for 12 V DC power line monitoring and control. Accurate current and temperature monitoring signals included. Programmable turn-on time for tailored response. Advanced fault detection and status flagging. Internal self-diagnostic MOSFET for enhanced reliability.
Compact surface mount QFN package suitable for tight spaces. Wide operating temperature range for versatile use. Explore more Electronic Fuses and power management components in the Electronics & Electricals category at EnvMart for comprehensive industrial and commercial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output current of this electronic fuse is 60A.
The maximum input voltage supported by the STEF12H60MPUR is 18V.
It operates effectively across a temperature range from -40°C to 125°C.
This model comes in a compact QFN package with a surface mount design.
The STEF12H60MPUR features 32 pins for reliable connectivity.
Yes, it includes overcurrent and fault status flags for reliable protection.
The height of this electronic fuse is 950μm.
The length of the STEF12H60MPUR is 5mm.
It is suitable for electronics manufacturing, automotive electronics, and industrial equipment requiring precise current and voltage monitoring.
It features programmable turn-on time for tailored response and accurate current and temperature monitoring signals.
The country of origin for this electronic fuse is India.
Yes, it supports parallel operation capability for scalability in higher current applications.
