Nexperia NPN Bipolar Small Signal Transistor, 500 mA, 45 V, 3-Pin SOT-23 BC817-25,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia NPN Bipolar Small Signal Transistor, 500 mA, 45 V, 3-Pin SOT-23 BC817-25,215

Name: Nexperia NPN Bipolar Small Signal Transistor, 500 mA, 45 V, 3-Pin SOT-23 BC817-25,215
Brand: Nexperia
SKU: 285544
Price: 0.06 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.11mm
Length	3mm
Model	BC817-25,215
Width	2.5mm
Mount Type	Surface
Series	BC817
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	45V
Minimum DC Current Gain hFE	160
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	50V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	500mA
Transistor Configuration	Single
Maximum Transition Frequency ft	100MHz
onsemi BC817-25LT1G Transistor, 500 mA NPN, 45 V, 3-Pin SOT-23Brand	onsemi
NXP BC817-25,215 NPN Bipolar Transistor, 500 mA, 45 V, 3-Pin TO-236ABBrand	NXP
INF NPN transistor,BC817-25 0.5A Ic 1VceBrand	Infineon

Key Features

The transistor package is compact SOT-23 surface mount with 3 pins.
It operates at a maximum power dissipation of 250 mW and transition frequency up to 100 MHz.
The device meets RoHS compliance and automotive standard AEC-Q101.
The operating temperature range extends from -65°C to 150°C.
The minimum DC current gain (hFE) is 160, allowing effective amplification.
The transistor is configured as a single device with NPN polarity for modular circuit design.

Product Description

Nexperia BC817-25,215 is a high-quality NPN bipolar small signal transistor optimized for switching and amplification applications in electronic circuits.

Designed with a 3-pin SOT-23 surface mount package, it supports a maximum DC collector current of 500 mA and a maximum collector-emitter voltage of 45 V, ensuring robust performance under demanding conditions.

This transistor provides up to 250 mW power dissipation and operates with a transition frequency of 100 MHz, making it suitable for high-frequency signal processing.

Its minimum DC current gain of 160 guarantees efficient transistor action, while the device complies with RoHS standards and automotive grade AEC-Q101 certification, making it reliable for automotive and industrial use.

The wide operating temperature range from -65°C to 150°C enables stable operation in harsh environments. Physical dimensions measure approximately 3 mm in length, 2.5 mm in width, and 1.11 mm in height, contributing to compact PCB layouts.

The SOT-23 package type supports surface mounting on PCBs for efficient mass manufacturing. Maximum collector-base voltage rating is 50 V, enhancing the transistor's voltage handling capability. This transistor is ideal for use in industrial, automotive, consumer electronics, and communication equipment.

The device is designed for low noise and reliable switching in amplifiers and signal control circuits. Package contents usually include 1 transistor per unit, ready for insertion in assembly lines. Choose this Nexperia BC817-25,215 transistor for high-quality, reliable small signal amplification application needs.
