SICK Plastic Glass Fibre Optic Sensor NPN Output IP50 24V DC Response Time 16μs WLL180T-E232
Specifications
| Country of Origin | China |
|---|---|
| Brand | SICK |
| Response time | 16μs |
| Light Source | LED |
| Length | 34.6mm |
| Model | WLL180T-E232 |
| Depth | 71.9mm |
| IP Rating | IP50 |
| Width | 10.5mm |
| Housing Material | Plastic |
| Output type | NPN |
| Series | WLL180T |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | -25°C |
| Switching Frequency | 31.2kHz |
| Terminal type | Cable |
| Standards/Approvals | CE, UL |
| Maximum Supply Voltage | 24V dc |
| Fibre Optic Type | Plastic, Glass |
| SICK Fibre Optic Sensor, PNP/NPN Output, IP50 30V dcBrand | SICK |
Key Features
- This sensor offers a selectable response time up to 16 microseconds for rapid process detection.
- It supports sensing ranges up to 20 meters in through-beam systems and 1,400 mm in proximity setup.
- The device features a high switching frequency of 31.2 kHz suitable for industrial automation.
- The plastic housing ensures durability, rated at IP50 for protection against dust ingress.
- Operating temperature ranges from -25°C to 55°C, suitable for various ambient conditions.
- Its LED light source enables consistent performance even in dusty, misty, or spray environments.
- The sensor has cable terminals for straightforward electrical connections.
- Supports bus-compatible operation with anti-interference logic for networked setups.
Product Description
SICK WLL180T-E232 Plastic Glass Fibre Optic Sensor with NPN output operates on 24V DC and offers an exemplary response time of 16μs, ensuring rapid and reliable detection in industrial automation and control environments.
Designed for robust performance, this sensor features a plastic housing with an IP50 ingress protection rating that safeguards it against dust and other environmental factors, allowing use under challenging ambient conditions such as dust, spray, mist, and water jets.
The fibre optic sensor supports a sensing range of up to 20 meters in through-beam configuration and up to 1,400 mm in proximity mode, while the LED light source provides high-intensity illumination for consistent operation.
Equipped with a high switching frequency of 31.2 kHz, it assures precision detection in fast-paced manufacturing and automation lines. The device includes cable terminal connections for straightforward installation and supports bus-compatible configurations with integrated anti-interference logic to eliminate sensor cross-talk.
The WLL180T series incorporates a rotatable display screen with two four-digit digital displays that facilitate easy visualization of programming steps, status, and live output values. Parameter settings like hysteresis and time delays are fully programmable to adapt to specific applications.
This sensor finds industrial use cases in detecting printed circuit boards, measuring liquid levels in bottles, log detection and classification, monitoring pick-up positions of solar cells, and verifying presence and positioning in injection molding tools and gripper mechanisms.
The WLL180T-E232 is made in China and carries CE and UL approvals, making it compliant with international standards for safety and quality. This sensor offers selectable response times up to 16 μs for rapid process detection.
Supports sensing distances up to 20 m for through-beam and 1,400 mm for proximity systems. Features bus compatibility with anti-interference logic for multiple sensor networking. Includes a rotatable, high-visibility digital display for intuitive programming.
Enables flexible parameter adjustment with programmable hysteresis and time delays. Robust plastic housing rated IP50 supports reliable operation in harsh industrial environments. Utilizes LED light source ensuring stable detection even under contamination.
Wide operating temperature range from -25°C to 55°C suits diverse settings. CE and UL certified for quality and safety assurance. Explore more sensors and fibre optic devices in our Electronics & Electricals > Sensors > Fibre Optic Sensor category at EnvMart for comprehensive industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The response time of this sensor is 16 microseconds, allowing for rapid process detection in industrial applications.
It supports a sensing range of up to 20 meters in through-beam configuration and up to 1,400 mm in proximity mode.
This model features an NPN output type, suitable for various industrial automation applications.
The maximum operating temperature is 55°C, making it suitable for diverse ambient conditions.
The sensor has an IP50 rating, providing protection against dust ingress.
It has a high switching frequency of 31.2 kHz, which is beneficial for precision detection in fast-paced environments.
The WLL180T-E232 utilizes an LED light source for consistent performance even in challenging environments.
The dimensions of the sensor are 34.6 mm in length, 10.5 mm in width, and 71.9 mm in depth.
The minimum operating temperature is -25°C, allowing it to function in colder environments.
Yes, it supports bus-compatible operation with anti-interference logic for networked setups.
This sensor carries CE and UL approvals, ensuring compliance with international safety and quality standards.
It features cable terminals for straightforward electrical connections during installation.
