SICK Light Intensity Sensor Blue LED 150 mm NPN/PNP 100 mA IP67 30V dc

SICK LUT9B-11626 Light Intensity Sensor with Blue LED offers advanced optical detection capabilities with a maximum detection distance of 150 mm and a high switching frequency of 6.5 kHz. Designed with a metal housing and an IP67 rating, it delivers reliable performance in demanding industrial environments.

The sensor features a simple teach-in function for optimal sensitivity adjustment and includes a bar graph display to visualize luminescence intensity continuously. Its NPN/PNP output type and maximum current rating of 100 mA make it compatible with a wide range of control systems. It supports a 30V dc supply voltage and comes equipped with an M12 male connector terminal for easy wiring.

With operating temperatures ranging from -10°C to 55°C and additional optical filters to suppress background luminescence, this sensor is well-suited for applications requiring precise light intensity measurement. The durable metal housing ensures long-term protection, while the blue LED light source improves sensor accuracy.

Key industrial applications include safety feature checking, monitoring adhesive layers, and detecting knots for length optimization in manufacturing processes. The LUT9 sensor series with IO-Link allows remote monitoring and configuration through machine control systems, enabling cost-effective diagnostics and data collection.

Manufactured in Germany and compliant with CE, RoHS, and IEC standards, the LUT9B-11626 sensor is ideal for industrial automation, quality control, and registration sensor applications.

Features a simple teach-in for easy sensitivity adjustment. Operating range of up to 250 mm with a maximum detection distance of 150 mm. Supports NPN/PNP output with a maximum current of 100 mA. Equipped with a blue LED light source and M12 male connector terminal.

Housed in metal with an IP67 ingress protection rating for robust protection. Operating temperature range from -10°C to 55°C ensures durable use. Features LED status display and operates at 30V dc supply voltage. Switching frequency is 6.5 kHz for high-speed sensing.

Includes bar graph display for luminescence intensity monitoring. Manufactured in Germany with CE, RoHS, and IEC approvals. Explore the full range of advanced Sensors in the EnvMart automation & control gear category for industrial and manufacturing solutions.
