Hongfa Europe GMBH PCB Signal Relay 5V DC Coil, 2A Switching Current, DPDT Contact Configuration HFD27/005-H
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 9.9mm |
| Length | 20mm |
| Model | HFD27/005-H |
| Width | 9.9mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | HFD27 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | PCB Terminal |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 125Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 200mW |
| Switching Power | 60W |
| Outline Dimensions | (20.2 x 10.0 x 11.5) mm |
| High switching capacity | 125VA/60W |
Key Features
- Operates with a coil voltage of 5V DC ensuring efficient performance.
- Supports a maximum switching current of 2A suitable for moderate load circuits.
- Designed with DPDT (Double Pole Double Throw) contact configuration for versatile switching options.
- Compact dimensions approximately 20mm length, 9.9mm height and width for PCB mounting.
- High switching power rating of 60W supporting various AC/DC voltages up to 250V AC and 220V DC.
- Gold plated contacts ensure durability and reliable conductivity.
- Epoxy sealed for protection and compatible with automatic wave soldering processes.
- Operating temperature range from -40°C to 70°C for stable industrial use.
Product Description
Hongfa Europe GMBH HFD27/005-H PCB Signal Relay is a high performance signal relay optimized for industrial and electronic applications requiring precise and reliable switching control at low power consumption.
Featuring a 5V DC coil voltage and a Double Pole Double Throw (DPDT) contact configuration, this signal relay is capable of switching currents up to 2A with a maximum switching power of 60W. The relay contacts are gold plated, providing excellent electrical conductivity and resistance to corrosion, thereby enhancing longevity and reliability in demanding environments.
The relay's compact size, with outline dimensions approximately 20.2 x 10.0 x 11.5 mm, allows for convenient PCB mounting using its PCB terminals. It is epoxy sealed, suitable for automatic wave soldering and cleaning processes, making it well-suited for mass production environments.
Designed to operate within a temperature range from -40°C to +70°C, the relay is robust for use in industrial, automation, and electronic control systems. It meets RoHS compliance, reflecting its environmentally responsible design.
Additional features include bifurcated contacts and compatibility with a 16 pin IC socket, simplifying installation and integration into circuit boards and automation control units.
Operates at 5V DC coil voltage ensuring low power consumption. DPDT contact configuration enables multiple switching paths. Switching current of 2A supports diverse load requirements. Gold plated contacts offer durable and stable electrical connection.
Epoxy sealed construction enables resistance to environmental factors and supports automated soldering. Compact size facilitates PCB mounting and integration into electronic assemblies. RoHS compliant for environmental safety and regulatory adherence.
Temperature rating from -40°C to 70°C allows for wide industrial applicability.
This Signal Relay is ideal for use in industrial control, automation, HVAC, instrumentation, and other electronics requiring reliable switching performance with low coil voltage operation.
Explore the comprehensive selection of relays in the Electronics & Electricals category on EnvMart to find precise components tailored to your technical and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 5V DC, ensuring efficient performance in low power consumption applications.
This model supports a maximum switching current of 2A, making it suitable for moderate load circuits.
It features a Double Pole Double Throw (DPDT) contact configuration, allowing for versatile switching options.
The outline dimensions are approximately 20.2 mm in length, 10.0 mm in width, and 11.5 mm in height, facilitating PCB mounting.
The relay has a maximum switching power rating of 60W, supporting various AC and DC voltages up to 250V AC and 220V DC.
The contacts are gold plated, which enhances conductivity and resistance to corrosion, contributing to reliability.
It operates within a temperature range from -40°C to +70°C, making it suitable for various industrial applications.
Yes, it is epoxy sealed, making it suitable for automatic wave soldering and cleaning processes, ideal for mass production environments.
This model uses PCB terminals for easy mounting on printed circuit boards.
The relay is RoHS compliant, indicating its adherence to environmental safety regulations.
The contact resistance is 100 mΩ, which contributes to its efficient performance in switching applications.
This relay is ideal for use in industrial control, automation, HVAC, instrumentation, and other electronics requiring reliable switching performance.
