ABB 4-Pole DIN Rail Isolator Switch, 25A, IP40/IP20, 3-Phase, SD204 Series 2CDD284101R0025 SD204/25
Specifications
| Country of Origin | India |
|---|---|
| Brand | ABB |
| Length | 70mm |
| Model | 2CDD284101R0025 SD204/25 |
| Depth | 88mm |
| IP Rating | IP40, IP20 |
| Width | 69mm |
| Mount Type | DIN Rail |
| Series | SD204 |
| Maximum Operating Temperature | 55°C |
| Minimum Operating Temperature | -25°C |
| Switching Current | 25A |
| Terminal type | Screw |
| Electrical Phase | 3 |
| Handle Colour | Grey |
| Number of Poles | 4 |
| Standards/Approvals | VDE, RoHS, CE |
| Switching DC Voltage | 131V dc |
| Switching AC Voltage | 462V ac |
Key Features
- Equipped with 4 poles suitable for 3-phase systems.
- Mount type is DIN Rail ensuring easy installation.
- Rated for operating temperatures from -25°C to 55°C.
- IP40 and IP20 rated providing robust protection against dust and solid objects.
- Includes auxiliary contacts for monitoring and control.
- Features padlock compatibility for enhanced safety.
- Rated switching voltages up to 462V AC and 131V DC.
- Complies with VDE, RoHS, and CE standards.
Product Description
ABB 2CDD284101R0025 SD204/25 is a 4-Pole DIN Rail Isolator Switch designed for industrial electrical safety and control applications. It belongs to the SD204 series, part of the System pro M compact® product range, known for state-of-the-art safety and comfort features.
This device supports a 25A switching current and is rated for 3-phase electrical systems with switching AC voltage up to 462V and DC voltage up to 131V. The isolator switch offers padlock compatibility, enabling secure maintenance operations.
The switch features a clear real contact position indication (Real CPI) marked in red and green, supporting easy visual verification of switch status. It has screw-type terminals with protection against misconnection and is compatible with all MCB accessories from the System pro M series. The grey handle is designed for ergonomic operation.
Operating temperature ranges from -25°C to 55°C, making it suitable for various industrial environments. The device is built to comply with commonly recognized standards including VDE, RoHS, and CE, ensuring quality and safety requirements are met.
Key technical dimensions include a length of 70mm, width of 69mm, and depth of 88mm, fitting within compact DIN rail enclosures. Its electrical phase compatibility is three-phase, and it can handle rated conditional short-circuit currents of 25 kA.
This isolator switch is widely applicable in electrical automation, industrial control panels, and switchboard assemblies, providing reliable isolation to protect personnel and equipment during maintenance or faults.
Equipped with 4 poles suitable for 3-phase systems. Mount type is DIN Rail ensuring easy installation. Rated for operating temperatures from -25°C to 55°C. IP40 and IP20 rated providing robust protection against dust and solid objects.
Includes auxiliary contacts for monitoring and control. Features padlock compatibility for enhanced safety. Rated switching voltages up to 462V AC and 131V DC. Complies with VDE, RoHS, and CE standards. Grey handle color with clear real CPI contact position indication.
Compact dimensions at 70mm length, 69mm width, and 88mm depth. Explore more Isolator Switches and electrical components in the Electronics & Electricals section on EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The isolator switch is rated for a switching current of 25A.
It can handle switching voltages up to 462V AC and 131V DC.
The dimensions are 70mm in length, 69mm in width, and 88mm in depth.
The switch has an IP rating of IP40 and IP20, providing protection against dust and solid objects.
It is designed for DIN Rail mounting, which facilitates easy installation.
The operating temperature range is from -25°C to 55°C.
Yes, it includes auxiliary contacts for monitoring and control.
It complies with VDE, RoHS, and CE standards.
The switch features screw-type terminals with protection against misconnection.
Yes, it is equipped with 4 poles suitable for 3-phase electrical systems.
The handle is grey in color and designed for ergonomic operation.
It can handle rated conditional short-circuit currents of 25 kA.
