Intelligent LED Solutions OSCONIQ P 3030 LED Array Red 1-LED 1A, 0.76W, 20mm Diameter ILH-PO01-RED1-SC221-WIR200.

Intelligent LED Solutions ILH-PO01-RED1-SC221-WIR200. is a high-performance OSCONIQ P 3030 LED Array featuring a single red LED designed for superior optical power and compact integration. Operating at 1A current with a power dissipation of 0.76W, this LED array delivers a typical luminous flux of 71lm and is equipped with an onboard driver and integrally molded silicone resin lens offering 120 to 130 degrees beam angle.

The compact 20mm diameter and height of 3.23mm make it suitable for space-constrained applications, including horticultural lighting, electronics displays, and indicator lighting where precise color and intensity control are essential. The aluminium substrate base ensures efficient thermal management to prolong LED life up to 50,000 hours at 70% brightness retention.

This LED array supports constant voltage operation with LED voltage between 1.9 and 2.5 volts, connected via solder terminals. Fixing holes fit M3 screws to facilitate secure mounting in varied industrial and commercial lighting assemblies.

Certified to RoHS standards, the product delivers reliable red light wavelength emission with included secondary optics to optimize beam pattern without automotive certification.

Applications span industrial indicators, horticultural lighting systems, electronic signage, and optical sensor arrays. Complementary accessories include suitable heatsinks and matching power supplies to optimize performance and integration ease.

Features a single red OSCONIQ P 3030 LED with integrated lens and onboard driver. Typical luminous flux is 71 lumens offering high brightness. Compact dimensions of 20mm outside diameter and 3.23mm height for versatile mounting.

Includes 200mm wires and fixing holes compatible with M3 screws for easy installation. Operates at 1.9 to 2.5V LED voltage with constant voltage output type. Constructed with aluminium substrate for optimal thermal management in horticultural and electronic applications.

Meets RoHS standards with included secondary optics for enhanced light distribution. Designed and manufactured in the United Kingdom with high quality assurance.

For users seeking reliable, high-performance LED arrays for industrial, laboratory, horticultural, or electronic display usage, this model offers a proven solution with robust build quality. Explore related Intelligent LED Solutions products in EnvMart’s Electronics & Electricals LED & Lights LED Arrays category for complementary components and upgrades.
