HY Electronic Corp Schottky Barrier Rectifier Diode 100 V 20 A TO-220AB MBR20100CT
Specifications
| Country of Origin | China |
|---|---|
| Brand | HY Electronic Corp |
| Mounting | Any position |
| Height | 8.24mm |
| Length | 10.5mm |
| Model | MBR20100CT |
| Width | 4.7mm |
| Mount Type | Through Hole |
| Series | FBI |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-220AB |
| Minimum Operating Temperature | -65°C |
| Polarity | markings on the device |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 150A |
| Maximum Forward Voltage Vf | 0.95V |
| TO220AC | 923-5498 |
| ITO220AC | 923-5514 |
Key Features
- Provides high current and high surge capability for robust operation.
- Features a low forward voltage drop of 0.95 V to minimize power loss.
- Operates efficiently up to a maximum temperature of 150°C.
- Designed with a common cathode diode configuration and three pins.
- Protected with a guard ring for transient voltage suppression.
- Plastic moulded TO-220AB package allows mounting in any position.
- Suitable for applications requiring fast switching and freewheeling in high frequency inverters.
- Device marked for polarity identification on the body.
Product Description
HY Electronic Corp MBR20100CT is a Schottky Barrier Rectifier Diode designed to deliver reliable high performance with a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 100 V. It is housed in a TO-220AB through-hole package with a three-pin configuration, suitable for power applications requiring fast switching.
This diode features a low forward voltage drop of 0.95 V, which minimizes power loss and increases efficiency in electronic circuits. Equipped with a guard ring, it provides transient voltage protection enhancing device robustness.
The device operates effectively within a temperature range from -65°C to 150°C, ensuring durability in harsh industrial, commercial, and laboratory environments. Its plastic moulded case meets UL 94V-0 flammability standards, offering safety and reliability.
The MBR20100CT diode is ideal for use in freewheeling applications in high frequency inverters, polarity protection, and rectification tasks where fast switching and low losses are critical. The common cathode configuration and three-pin design facilitate easy mounting and integration into power supply and electronic component assemblies.
High current, high surge capability for demanding applications. Low forward voltage drop reduces heat generation and energy waste. Wide operating temperature range supports industrial use. Guard ring protects against voltage transients.
Plastic TO-220AB package with UL 94V-0 certification. Polarity marking eases installation and maintenance. Three-pin through-hole mounting for solid mechanical and electrical connection. Suitable for power electronics, automotive, and industrial equipment.
Manufactured in China with consistent quality standards. Complies with standard environmental and safety approvals.
This Schottky diode is a versatile semiconductor device widely used in powering electronic circuits, with applications spanning industrial, laboratory, commercial, and automotive sectors. Browse more Schottky Diodes & Rectifiers and related semiconductor components on EnvMart to find complementary products suited to your design needs.
Explore more products in our Semiconductor Diode category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MBR20100CT has a maximum continuous forward current of 20 A.
The maximum forward voltage drop for this diode is 0.95 V.
It operates effectively within a temperature range from -65°C to 150°C.
The diode is housed in a TO-220AB package type.
This model features a three-pin configuration.
The MBR20100CT is designed with a common cathode diode configuration.
It can be mounted in any position due to its design.
The peak non-repetitive forward surge current rating is 150 A.
The plastic moulded case meets UL 94V-0 flammability standards.
The MBR20100CT is manufactured in China.
